Using Your Radio (Basic Operation)

Front Panel Controls
1 2
1 2
Page 16
3 4 5 6
Figure 10 - Front Panel Controls
Figure 11 - Shaft with Knobs
7 8 9 10
Both shafts are designed for a front
and rear knob, which have push func-
tionality. The photo on the left shows
the left shaft (1 and 2 in Figure 10) with
knobs installed. Use the "Operation
Table" on page 17 to determine how to
use the knobs to achieve the desired
response from your Model Two radio.
