1. Introduction
The SPLITMUX-C5HDR-4LC (SPLITMUX) is a high performance 4 by 1 Quad Multi-Viewer
with seamless switcher. It supports four High-definition input sources displaying on one
screen, and has three multi-view effect modes. As a switcher, it can also seamlessly switch
the four HD inputs freely. The SPLITMUX can be controlled by the front panel buttons,
IR control, or RS232 control.
source audio at the same time.
The SPLITMUX can also extend the video and audio signals over a single CAT5e/6/6a/7
cable up to 250 foot (76m) with
2. Features
Compliant with HDMI 1.3a,HDCP 1.2
Supports multiplexed HDMI 4-input and 1-output
Supports up to 1080p High Definition resolution
Supports 4by1 Quad Multi-viewer and seamless switch
Supports scale-up/scale-down function
Supports multi-output resolution
Supports digital audio format
Supports button, IR and RS232 control
IR system allowing for control of source at display end
Allows HDMI Audio/Video and IR signals to be transmitted over a single Cat5e/6/6a/7
cable

3. Package Contents

1-SPLITMUX-C5HDR-4LC HDMI Quad Multi-Viewer
1-CAT5e/6 Remote Unit
1-12V/2.5A DC power adaptor
1-5V/1A DC power adaptor
1-Remote Control
2-Wide-band IR Receiver
5-Wide-band IR Transmitter
1-RS232 Cable (4.6ft 9DB male to 9DB female)
2-Wall mount brackets with case-mounting screws
1-CD with Operation Manual and RS232 Control Application
The SPLITMUX provides an S/PDIF link to output the HDMI
Bi-directional IR control (see table on page 8).
LPCM/AC3/DTS
1
