INSTALLING THE HANDLE

Do not over-tighten the
IMPORTANT:
screws and do not use power
tools to install the handle.
1 2 3
Locate the handle (1) over the pins
(3) of the door and tighten the
handle by screwing the Allen key
grub screws (2).

REVERSING THE DOOR HINGE

It is possible to reverse the door
on this appliance, if required.
To do so, follow the steps below:
All parts must be saved for
Note:
reinstallation of the door.
1. Remove the glass door by
unscrewing
screws (3) and (4). Be careful to
hold the glass door firmly after
removing the screws and place
it on a padded surface to avoid
the risk of damage.
the eight lock
2. Unscrew and transfer the door
supporter (2) to the opposite side.
3. Rotate the glass door 180° and refit
the glass door to the opposite side.
Then screw and tighten it after the
door is leveled.
4. Remove the handle from the left side
of the door and install it on the right
side.
8
