FULLY INTEGRATED BUILT-IN-COLUMN
INSTALLATION
The wine cellar door seals the
installed unit almost completely, so
an air vent must be provided in the
base of the housing. Warmed air
must be conducted via the
ventilation shaft to the rear wall of
the housing and then expelled
upwards. The ventilation channels
should measure at least 31 in
square centimeters) in cross-
section.
Model A
17.36"
VC28S
(44.1cm)
34.29"
VC60D
(87.1cm)
Warning: To ensure the proper
functioning of the appliance, air
vents should never be blocked or
covered.
2
(200
B C
17.91" 17.72"
(45.5cm) (45cm)
34.84" 34.37-34.57"
(88.5cm) (87.3-87.8cm)
