INTEGRATED WINE CELLARS
Model VC28S
Please read this manual carefully before installing and starting up, and store
it in a safe place.
Write Serial Number here:
________________________
INSTRUCTION MANUAL
Model VC60D
Felix Storch, Inc.
Summit Appliance Division
770 Garrison Avenue
Bronx, New York 10474
Tel.: 718-893-3900
Fax: 718-842-3093
www.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit VC60D
Summary of Contents for Summit VC60D
- Page 1 INTEGRATED WINE CELLARS Model VC28S Model VC60D INSTRUCTION MANUAL Please read this manual carefully before installing and starting up, and store it in a safe place. Felix Storch, Inc. Summit Appliance Division Write Serial Number here: 770 Garrison Avenue Bronx, New York 10474 ________________________ Tel.: 718-893-3900...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFEGUARDS ................2 - 3 DISPOSAL ....................... 3 PRODUCT FEATURES ....................4 INSTALLATION ....................5 – 8 Before using your wine cellar ..............5 Installation of your wine cellar .............. 5 Fully integrated built-in-column installation .......... 6 Electrical connection ................ -
Page 3: Important Safeguards
Do not connect or disconnect the • IMPORTANT SAFEGUARDS electric plug when your hands are When using an electrical appliance, basic wet. precautions should always be followed. Unplug the appliance or • Read all instructions carefully, even if disconnect power before cleaning you are already familiar with the or servicing. -
Page 4: Disposal
state and local codes. A standard If you have a lockable appliance, • electrical supply (115V AC only, 60 do not keep the key near the Hz), properly grounded in accordance appliance or within reach of with the National Electrical Code and children. -
Page 5: Product Features
Built-in (integrated) installation • from UV light and creates an with single (VC28S) or dual attractive display with little (VC60D) temperature zone. condensation and low noise. Continuously variable electronic • Black coated matte steel outer •... -
Page 6: Installation
blocked in any way so that air INSTALLATION circulation can occur freely. Locate the unit away from direct BEFORE USING YOUR WINE CELLAR sunlight and sources of heat Remove all exterior and interior (stove, heater, radiator, etc.). packing. Clean the interior Direct sunlight may affect the surface with lukewarm water finish and heat sources may... -
Page 7: Fully Integrated Built-In-Column Installation
31 in (200 square centimeters) in cross- section. Model 17.36” 17.91” 17.72” VC28S (44.1cm) (45.5cm) (45cm) 34.29” 34.84” 34.37-34.57” VC60D (87.1cm) (88.5cm) (87.3-87.8cm) Warning: To ensure the proper functioning of the appliance, air vents should never be blocked or covered. -
Page 8: Electrical Connection
behind the appliance and should ELECTRICAL CONNECTION not be allowed to lie or hang : Improper use of the grounded Warning unprotected. plug can result in the risk of electrical The appliance should always be shock. If the power cord is damaged, plugged into its own individual have it replaced by a qualified electrical outlet which has a voltage... -
Page 9: Installing The Handle
INSTALLING THE HANDLE Do not over-tighten the IMPORTANT: screws and do not use power tools to install the handle. 2. Unscrew and transfer the door supporter (2) to the opposite side. 3. Rotate the glass door 180° and refit the glass door to the opposite side. Then screw and tighten it after the door is leveled. -
Page 10: Operating Your Wine Cellar
OPERATING YOUR USE AND CONTROL – SINGLE WINE CELLAR ZONE This appliance is designed for operation The Controls of Your VC28S Wine at certain ambient temperatures. The Cellar climate class is specified on the rating plate. The appliance may not work properly if it is left for a long period at a temperature Power outside the specified range. -
Page 11: Use And Control - Dual Zone
Select the temperature display setting in USE AND CONTROL – DUAL ZONE Fahrenheit or Celsius degrees. To change the temperature from Fahrenheit to The Controls of Your VC60D Wine Cellar Celsius or from Celsius to Fahrenheit, press and hold the Light key for 5 seconds. - Page 12 for the Upper temperature zone Display is 10°C/50°F and for the Lower Digitally displays the temperature temperature zone is 16°C/60°F. and service indicators. • You can press the left side Up and is for Upper temperature zone and Down keys to control the internal is for Lower temperature zone.
-
Page 13: Temperature Display
flash in the display for 5 seconds. appliance recognizes as being too warm or too cool. Afterwards, the display will show the The alarm will sound and the current inner temperature again. temperature display will flash: - When you switch the appliance TEMPERATURE DISPLAY on, if the temperature inside the During normal operation, the... -
Page 14: Dynamic Climate / Silent Mode
mark toggles between 2 modes of SABBATH MODE operation for the internal lights: Sabbath mode is available for the functional (default) mode and observance of certain religious showcase mode. If you are in holidays. This mode turns off the functional (default) mode, the lights displays, interior light and audible will turn on only when the door is alarms and prevents them from... -
Page 15: Defrosting / Humidity / Ventilation
DEFROSTING / HUMIDITY / maximums when storing traditional VENTILATION Bordeaux 750-ml bottles and include bulk storage. Your wine cellar is designed with an automatic defrost system. During “Off- You may load your wine bottles in cycle”, the evaporator behind the rear single row or by stacking while taking note of the following: if you wall of the unit defrosts automatically. -
Page 16: Wine Serving Temperature Chart
WINE SERVING TEMPERATURE CHART IMPORTANT INFORMATION ABOUT TEMPERATURE The chart below indicates the best temperature for drinking purposes. Your wine cellar has been designed to guarantee optimum conditions Wine Style °C °F for storing and/or serving your Champagne NV, Sparkling, wines. -
Page 17: Notes On Wine Storage
NOTES ON WINE STORAGE • Only store wine in unopened bottles. Always lay bottles on their side for storage. • Do not overload the cabinet. • Do not open the door unless necessary. • Do not cover shelves with aluminum foil or any other shelf material which may prevent air circulation. -
Page 18: Care And Maintenance
area of the controls. CARE AND MAINTENANCE • Wash the outside cabinet with Warning: Failure to unplug the appliance warm water and mild liquid during service and cleaning could result detergent. Rinse well and wipe in electrical shock or other personal dry with a clean soft cloth. -
Page 19: Vacation Tine
and frequent exposure to these than necessary. abnormal conditions can cause a • Store contents in an organized detrimental effect on your wines. way. • To allow air to circulate, do VACATION TIME not overfill the appliance. • Short holidays: Leave the Wine Cellar in operation for holidays of less than three weeks. -
Page 20: Problems With Your Wine Cellar
PROBLEMS WITH YOUR WINE CELLAR You can solve many common Wine Cellar problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling customer service. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY... - Page 21 • The appliance has not been leveled • Level the appliance with the properly. adjustable feet. • The door was reversed and not • Check the door hinge and The door will not properly re-installed. reassemble correctly. close completely. • The gasket is dirty. •...
- Page 22 NOTES...
- Page 23 NOTES...
-
Page 24: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory- specified parts and repair labor to correct defects in materials or workmanship.
