4.13

COMMUNICATOR 4 BY 2 FORMAT

☞ NOTE: Section 4.13 pertains to the 4 by 2 communicator format
only.
PURPOSE:
For confi guring how the 4 by 2 format will report to the Central Station.
General reporting or Point-to-Point reporting methods are available for
the 4 by 2 format.
GENERAL REPORTING: General reporting can send fi ve report codes for
sensors: FIRE, EMERGENCY, POLICE, BURGLARY and TROUBLE. General
reporting does not indicate which sensor caused the report.
POINT-TO-POINT REPORTING: Point-to-Point reporting sends each sensor/
zone number with a unique ALARM code and TROUBLE code.
☞ NOTE: With either reporting method, the Console alarm codes are
the same (see Section 4.13.5).
USER RESPONSE:
4 BY 2 FORMAT
✦ Select POINT-TO-POINT to have the Console's communicator send
4 by 2 Point-to-Point report codes. Select GENERAL to have the
Console's communicator send only the fi ve 4 by 2 General report
codes.
29
