Main Pcb Block - Casio QT-6600 Service Manual

1 QT-6600C
2 QT-6600B
3 QT-6600BD
N Item

1. MAIN PCB BLOCK

1
IC1
IC2
IC3
IC4
IC5
IC6,IC7
IC8,IC9
IC10
IC11,IC45
IC12
IC13,IC14
IC15
IC16
IC17
IC18
IC19
IC20,IC21
IC22,IC23
IC24-IC29
IC30
IC31
IC32
IC33
IC34
IC36
IC37
IC38,39
IC42
IC43
IC44
IC40,IC41,46
R1,R12,R314,R363,R428
R2-R6,R8,R14,R28,R31,
R37,R284-R287,
R289-R291,R313,R320,
R321,R329,R339,R346,
R348,R355,R356,R358,
R360,R365,R366,R368,
R372,R373,R377,R378,
R394,R397,R433,R434,
R441,R448,R452
R7,R11,R13,R15,R18,
R20,R21,R33,R38,R40,
R56,R65,R80,R81,R167,
R169,R171-R174,R194,
R207,R208,R227-R229,
R241,R243,R257-R261,
R274-R277,R293-R295,
R328,R364,R367,R370,
R371,R374-R376,R385,
R386,R432,R437,R449,
R450,R453-R459
R9,R34,R57,R340,R342,
R383,R384,R436,R446
Code No. Parts Name
10322428 PCB ASSY/E830-1
10261121 IC
10275575 IC
10315229 LSI
10315230 LSI
10316453 IC
10272416 SDRAM
10315231 SGRAM
IC
10315232 FLASH MEMORY
10319163 FLASH MEMORY
10166803 IC/CMOS
10205905 LSI
10272413 LSI
10213989 LSI
10147316 IC
10316452 IC
10105408 IC/CMOS
10005721 IC/CMOS
10295605 IC
10105416 IC/CMOS
10315233 LSI
10316455 IC
10319145 IC
10316450 LSI
10275573 IC
10116986 IC
IC
10166805 IC/CMOS
21056580 IC/CMOS
10007179 IC/CMOS
10316456 IC
RESISTOR/CHIP
RESISTOR/CHIP
RESISTOR/CHIP
RESISTOR/CHIP
Specification
RJE502811*001V01
BA33DD0WHFP-TR
RV5C348A-E2-FB
R5S77631AY266BGV
MB86276PB-G-ZE1
SN75LVDS83DGGR
MT48LC4M16A2P-75:G
HYB25DC256163CE-5
BD3533HFN-TR
S29GL256P90TFCR20
S29GL256P90TFCR2AA
SN74ALVCH16245DGGR
UPD65945GJP16-JEUA
LAN9115-MT
MSM9841G3-2K
SN74LVC1G97DCK3
BD7830NUV-TR
SN74LVC245APWR
SN74LV244APWR
MAX3243ECPWR
SN74AHCT08PWR
UPD70F3728GC-8BT-A
PQ025ENAHZPH
PQ018ENA1ZPH
BD9130NV-E2
XC6215B332MR
SN74AHCT1G08DCKR
LM2676SX-ADJ/NOPB
SN74ALVC08PWR
SN74LV14APWR
SN74LV10APWR
XC6108N33AMR
WR06X000PTL
WR06X103JTL
WR04X563JTL
WR06X102JTL
— 121 —
Q'ty Price
Rank
Code
1 2 3
1 1 1 EU A
1 1 1 AH C
1 1 1 AC C
1 1 1 DD C
1 1 1 CJ C
1 1 1 BO C
2 2 2 BR C
2 2 2 BB C
1 1 1
2 2 2 CH C
1 1 1 CL C
2 2 2 BF C
1 1 1 BU C
1 1 1 BN C
1 1 1 BG C
1 1 1 AB C
1 1 1 AP C
2 2 2 AA C
2 2 2 AF C
6 6 6 AW C
1 1 1 AC C
1 1 1 BJ C
1 1 1 AP C
1 1 1 AL C
1 1 1 AZ C
1 1 1 AE C
1 1 1 AA C
2 2 2
1 1 1 AH C
1 1 1 AC C
1 1 1 AC C
2 2 2 AD C
5 5 5
42 42 42
63 63 63
9 9 9
