2. Hi8/standard 8mm AFM 1.5 MHz Deviation
Adjustment (VC-213 board)
Adjust to the optimum 1.5MHz audio FM signal deviation.
If the adjustment is not correct, its playback level will differ from
that of other units.
Mode Playback
Signal Hi8/standard 8mm alignment tape:
For checking AFM stereo operation
Monoscope section
Measurement Point Audio output terminal left or right
Measuring Instrument Audio level meter
Adjustment Page F
Adjustment Address 62
Specified Value –7.5 ± 2.0dBs
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Set the Hi-Fi sound switch (menu display) to "1".
3) Select page: F, address: 62, change the data and set the 400Hz
signal level to the specified value.
4) Press the PAUSE button.
5) Set the Hi-Fi sound switch (menu display) to "STEREO".
6) Select page: 0, address: 01, and set data: 00.
3. Hi8/standard 8mm AFM 1.7 MHz Deviation
Adjustment (VC-213 board)
Adjust to the optimum 1.7MHz audio FM signal deviation.
If improper, this causes deteriorated separation (with stereo signal).
Mode Playback
Signal Hi8/standard 8mm alignment tape:
For checking AFM stereo operation
Monoscope section
Measurement Point Audio output terminal left or right
Measuring Instrument Oscilloscope
Adjustment Page F
Adjustment Address 63
Specified Value –7.5 ± 2.0dBs
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Set the Hi-Fi sound switch (menu display) to "2".
3) Select page: F, address: 63, change the data and set the 1kHz
signal level to the specified value.
4) Press the PAUSE button.
5) Set the Hi-Fi sound switch (menu display) to "STEREO".
6) Select page: 0, address: 01, and set data: 00.
(WR5-9NS(NTSC))
(WR5-9CS(PAL))
(WR5-9NS(NTSC))
(WR5-9CS(PAL))
4. Digital8 Playback Level Check
Mode
Signal
Measurement Point
Measuring Instrument
Specified Value
Checking Method:
1) Check that the playback signal level is the specified value.
5. Overall Level Characteristics Check
Mode
Signal
Measurement Point
Measuring Instrument
Specified Value
Checking Method:
1) Input the 400Hz, –66dBs signal in the MIC jack.
2) Record in the camera mode.
3) Playback the recorded section.
4) Check that the 400Hz signal level is the specified value.
6. Overall Distortion Check
Mode
Signal
Measurement Point
Measuring Instrument
Specified Value
Checking Method:
1) Input the 400Hz, –66dBs signal in the MIC jack.
2) Record in the camera mode.
3) Playback the recorded section.
4) Check that the distortion is the specified value.
5-64
VTR playback
Digital8 alignment tape:
For audio operation check
(WR5-3ND (NTSC))
(WR5-3CD (PAL))
Audio output terminal left or right
Audio level meter and frequency counter
32 kHz mode: 1 kHz, +3.0 ± 2.0dBs
48 kHz mode: 1 kHz, +3.0 ± 2.0dBs
44.1 kHz mode:
The 7.35kHz signal level during EMP
OFF is +2.0 ± 2.0dBs.
The 7.35kHz signal level during EMP
ON is –6 ± 2 dB from the signal level
during EMP OFF.
Camera recording and playback
400Hz, –66 dBs signal: MIC jack left
and right
Audio output terminal left or right
Audio level meter
–7.5 ± 3.0dBs
Camera recording and playback
400Hz, –66dBs signal: MIC jack left
and right
Audio left or right terminal of AUDIO

VIDEO jack

Audio distortion meter
Below 0.4%
(200Hz to 6kHz BPF ON)
