Sony Digital8 DCR-TRV410 Service Manual page 153

1-5. IC351(VFD) BIST(PB) Check
1) Select page: 0, address: 01, and set data: 01.
2) Select page: C, address: 51, set data: 0F, and press the PAUSE
button.
3) Only for the DCR-TRV510/TRV510E model, select page: C,
address: 60, set data: 00, and press the PAUSE button.
• VBUS/EX BIST(PB) Check
4) Select page: 3, address: 10, set data: 00, and press the PAUSE
button.
5) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
6) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
7) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
8) When the playback system from IC301(SFD) to IC351(VFD)
is normal, the display data (combination data) of page: 3,
address: 14 and 15 agrees with any combination as shown
below.
NTSC model PAL model
Address Data Address
14 12
15 43
9) When the playback system from IC351(VFD) to IC251(DCR-
TRV410/TRV410E) or IC606(DCR-TRV510/TRV510E) is
normal, the display data (combination data) of page: 3, address:
16 and 17 agrees with any combination as shown below.
NTSC model PAL model
Address Data Address
16 FB
17 F4
• UPY Y BIST(PB) Check
10) Select page: 3, address: 10, set data: 88, and press the PAUSE
button.
11) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
12) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
13) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
14) When the playback system from IC351(VFD) to IC4501,5502
(LCD DRIVER) is normal, the display data (combination data)
of page: 3, address: 16 and 17 agrees with any combination as
shown below.
NTSC model PAL model
Address Data Address
16 9A
17 13
Data
14 90
15 CE
Data
16 54
17 ED
Data
16 03
17 C9
• UPY Cr BIST(PB) Check
15) Select page: 3, address: 10, set data: 89, and press the PAUSE
button.
16) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
17) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
18) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
19) When the playback system from IC351(VFD) to IC4501,5502
(LCD DRIVER) is normal, the display data (combination data)
of page: 3, address: 16 and 17 agrees with any combination as
shown below.
NTSC model
Address Data
16 1C
17 60
• UPY Cb BIST(PB) Check
20) Select page: 3, address: 10, set data: 8A, and press the PAUSE
button.
21) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
22) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
23) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
24) When the playback system from IC351(VFD) to IC4501,5502
(LCD DRIVER) is normal, the display data (combination data)
of page: 3, address: 16 and 17 agrees with any combination as
shown below.
NTSC model
Address Data
16 92
17 5A
• ENC Ya BIST(PB) Check
25) Select page: 3, address: 10, set data: 8B, and press the PAUSE
button.
26) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
27) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
28) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
29) When the playback system from IC351(VFD) to IC643 (AOI)
is normal, the display data (combination data) of page: 3,
address: 16 and 17 agrees with any combination as shown
below.
NTSC model
Address Data
16 3C
17 D2
5-58
PAL model
Address Data
16 14
17 A7
PAL model
Address Data
16 B8
17 67
PAL model
Address Data
16 69
17 21
