Chapter 2: Jumpers and Connectors
System Fan
Connector type: 1x3 3-pin Wafer, 2.54 mm pitch
Connector location: FAN1
1
3
Pin Definition
1 GND
2 VCC12
3 FAN2
Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
System Fan
Connector type: 1x3 3-pin Wafer, 2.54 mm pitch
Connector location: FAN2
1
3
Pin Definition
1 GND
2 VCC12
3 FAN3
28
