Framework - Dahua IPC-HFW5100C User Manual

Model
Parameter
Main Processor
OS
System
Resources
User Interface
System Status
Image Sensor
Pixel
Day/Night Mode
Auto Aperture
Gain Control
White Balance
BLC
Exposure Mode
Video
Compression
Standard
Video Frame
Rate
Video Bit Rate
Video Flip
Snapshot
Privacy Mask
Video Setup
Video
Information
Lens
Lens Interface
Audio Input
Audio Output
have. (Subject to actual product)
IPC-HFW5300C（-H）
High performance DSP
Embedded LINUX
Support real-time network, local record, and remote operation at the
same time.
Remote operation interface such as WEB, DSS, PSS
Micro SD card status, bit stream statistics, log, and software version.
1/3.0-inch CMOS
2048(H)*1536(V)
Support day/night mode switch and IR-CUT at the same time.
(embedded IR-CUT)
Enable
Fixed/Auto
Manual/Auto
Off/BLC(default or custom)/WDR (0-100 adjustable)/HLC(0-100
adjustable)
Manual/Auto
It ranges from 1/3 to 1/100000, user customize)
H.264/H.264H/MJPEG
PAL:
Main stream (3M@20fps)
extra stream (D1@20fps, CIF@20fps);
Main stream (1080P@25fps)
extra stream (D1@25fps, CIF@25fps)
NTSC:
Main stream (3M@20fps)
extra stream (D1@20fps, CIF@20fps);
Main stream (1080P@30fps)
extra stream (D1@30fps, CIF@30fps)
H.264: 16-8192Kbps adjustable
MJPEG: 16-24576Kbps adjustable and bit rate is adjustable.
Support customized setup.
Support mirror and flip function.
Max 1f/s snapshot. File extension name is JPEG.
Supports max 4 privacy mask zones
Support parameter setup such as bright, contrast.
Channel title, time title, motion detect, camera masking.
Manual 3.3~12mm @F1.4
(subject to actual product)
Φ14. Lens is the default accessories
1-channel,RCA
1-channel, RCA
IPC-HFW5302C(-H)
3~9mm@F1.4
Motorized
(subject to actual product)
4
