System Status
Image Sensor
Pixel
Day/Night Mode
Auto Aperture
Gain Control
White Balance
BLC
Exposure Mode
Video
Compression
Standard
Video Frame
Rate
Video Bit Rate
Video Flip
Snapshot
Privacy Mask
Video Setup
Video
Information
Lens
Lens Interface
Audio Input
Audio Output
Bidirectional
Talk Input
Audio Bit Rate
Audio
Compression
Standard
Motion Detect
Alarm Input
Micro SD card status, bit stream statistics, log, and software version.
1/2.5-inch CMOS
2560(H)*1920(V)
Support day/night mode switch and IR-CUT at the same time.
(embedded IR-CUT)
Enable
Fixed/Auto
Manual/Auto
Off/BLC(default or custom)/WDR (0-100 adjustable)/HLC(0-100
adjustable)
Manual/Auto
It ranges from 1/3 to 1/100000)
H.264/H.264H/MJPEG
PAL:
Main stream (5M@12fps)
extra stream (D1@12fps, CIF@12fps);
Main stream (1080P@25fps)
extra stream (D1@25fps, CIF@25fps)
NTSC:
Main stream (5M@12fps)
extra stream (D1@12fps, CIF@12fps);
Main stream (1080P@30fps)
extra stream (D1@30fps, CIF@30fps)
H.264: 32-8192Kbps adjustable
MJPEG adjustable and bit rate is adjustable.
Support customized setup.
Support mirror and flip function.
Max 1f/s snapshot. File extension name is JPEG.
Supports max 4 privacy mask zones
Support parameter setup such as bright, contrast.
Channel title, time title, motion detect, camera masking.
3~9mm@F1.4
Motorized
Φ14. Lens is the default accessories
1-channel,RCA
1-channel, RCA
Reuse the first audio input channel
8kbps 16bit/16kbps 16bit
G.711A/G.711Mu/PCM
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
2-channel input,1-channel output
(subject to actual product)
