Dahua IPC-HFW5100C User Manual page 9

Video Flip
Snapshot
Privacy Mask
Video Setup
Video
Information
Lens
Lens Interface
Audio Input
Audio Output
Bidirectional
Talk Input
Audio Bit Rate
Audio
Compression
Standard
Motion Detect
Alarm Input
Record Priority
Local Storage
Storage
Management
Wire Network
Network Protocol
Remote
Operation
Video Output
Reset
Power
Power
Consumption
Working
Temperature
Working
Humidify
Dimensions(mm)
Weight
Installation
IR Distance
Protection Level
Note
Support customized
setup.
Support mirror and flip function.
Max 1f/s snapshot. File extension name is JPEG.
Supports max 4 privacy mask zones
Support parameter setup such as bright, contrast.
Channel title, time title, motion detect, camera masking.
Manual 2.8~12mm
@F1.4
Φ14. Lens is the default accessories
1-channel,RCA
1-channel, RCA
Reuse the first audio input channel
16kbps 16BIT
G.711A/G.711Mu/PCM
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
2-channel input,1-channel output
Manual>External alarm >Video detect>Schedule
Support Micro SD card hot swap
Support display local storage status
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
1-channel analog video output,BNC port
Reset button
AC 24V/PoE or DC 12V/PoE
7.5W MAX (-H series≤9W)
-30℃~+60℃(-H: -40°~60°)
≤95%
φ104×306.7
1250g(Excluding box)
Bracket is included as default.
20~30m
IP66
Model with "-H" means it has electrical heating, otherwise, it does not
Manual
3.3~12mm@F1.4
Motorized
3~9mm@F1.4
8.5W MAX (-H series
≤11.5W, PoE (AT
standard))
3
