2 Framework

2.1 Rear Panel

This series IP camera real panel is shown as below. See Figure 2-1.
Please refer to the following sheet for detail information.
Interface Name
VIDEO OUT
eLineTechnology.com
The rear panel with the network port
The rear panel with the 100M fiber port
Figure 2-1
Video output port
Connector
BNC
Function
Output analog video
signal. Can connect to
