EC Declaration of Conformity
iMove 50S
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
89/336/EEC.
EN55014-2: 1997 A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002;
EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6: 1996,
EN61000-4-11: 1994.
&
Harmonized Standard
EN60598-1: 2000+ALL: 2000+A12: 2002
Safety of household and similar electrical appliances
Part 1: General requirements
User Guide
Professional Entertainment Technology
Innovation, Quality, Performance
19A

Advertisement

loading
Need help?

Need help?

Do you have a question about the iMove 50S and is the answer not in the manual?

Questions and answers
