Bircher Reglomat PrimeMotion B Original Instructions

Microwave motion detector for opening automatically controlled doors

Advertisement

Quick Links

EN ISO
9001
Quality
international
level
PrimeMotion
Translation of the original instructions
General
PrimeMotion B
Safety instructions
1
Observe the national and international regulations on door safety.
Only trained, qualified personnel may mount and start up the detector.
The unit may only be opened and repaired by Bircher Reglomat.
The unit may only be operated from a safety extra-low voltage (SELV) system with safe electrical separation.
Always consider the safety functions of your application as a whole, never just in relation to one individual section of the system.
The installer is responsible for carrying out a risk assessment and installing the detector and the door system correctly.
Avoid touching any electronic components.
The door drive and transom profile must be earthed correctly.
Start-up
Recommended start-up sequence: I. Mounting
Montage
2
I
1. Remove cover hood
Mounting of the detector
1. Position drill template
2. Drill the holes, remove drill template
3. Lay cable and mount detector
3
Electrical connections
II
PrimeMotion B ES
1 brown
1
Power Supply
2 white
2
3 green
3
Relay
4 yellow
4
Mechanical fine tuning
4
Manual settings of the
inclination
0° ... +45° in 5° steps
– –
+ +
Manual settings of the
pivoting
– 20° ... +20° in 5° steps
+ +
– –
B
Radarfeld
II. Connection
2. Lay and connect cable
Controller
brown
11.5 - 36 VDC
3 m
white
12 - 28 VAC
green
Cable
Microwave
yellow
Wide radar field
+
Inclination angle: 35°
0m
1m
2m
3m
+
4m
min. = 0.5 x 0.25, max. = 4 x 2 m (WxD)
Microwave motion detector for opening
3. Mount detector
4 3 2 1
turn 90°
90°
0m
1m
2m
Year of construction 2010
automatically controlled doors
Hood,
Light window de-
tector indication,
no function,
Cable bushing,
Mounting holes,
Detector electronic,
Microwave module,
LED microw.: green
Narrow radar field
Inclination angle: 35°
0m
1m
2m
3m
2m
4m
min. = 0.16 x 0.8, max. = 2 x 4 m (WxD)
0m
1m
1
