Aquaglide Multisport 270 Owner's Manual page 9

B-10
11. Close the clamp to secure the boom on the mast. The clamp should
close with a snap when using firm pressure. Tighten the rope (if neces-
sary) by pulling it through the cleat in the front clamp. If it is too loose,
the boom will slip on the mast. If it is too tight, the clamp will not close.
B-11
12. Next, connect the back corner of the sail, known as the clew. Feed
the boom clew line through the gromet in the clew of the sail as shown in
photo B12.
B-12
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
Multisport
B-13
B
13. Thread the line around the retainer at the back of the boom (A),
through the clew gromet a second time (B) and to the back of the boom
again (C) as shown in photo B13.
14. Engage the line in the embedded cleat as shown in B14.
B-14
15. Wrap the remaining line around the boom tube with several turns,
making sure to keep the line engaged in the cleat. Secure the tail by
tucking it under a previous turn and cinching tight.
B-15
TEL: (509) 493-4938 FAX: (509) 493-4966
270 Owner's Manual
™
C
A
Cleat
for more info go to:
www.Aquaglide.net
9
