D-6
6. The rig is now attached. Please note: in windsurfing mode, the sailing
rig can move about freely on the bast base. It is expected to rest in the
horizontal position as shown in photo D6.
E. Attaching the Keels
1. Same as sailboat assembly begining on page 17, except:
E-2
2. Do not attach the rudder.
3. Do not attach the tiller handle.
E-3
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
Multisport
E-4
4. After installing the center keel, insert the second keel (two shafts) into
the keel slots in the back of the hull as shown in photo E4. Wiggle the
keel slightly, pushing it inward until it touches the hull.
5. Secure the keel to the hull with the elastic keel retainer. Make sure the
elastic is fully captured in the keel hook as shown in photo E5.
E-5
F. Assembly Complete - Now What?
1. This completes the Multisport™ 270 windsurfing assembly. Before
taking off for your first sail, be sure to read and understand the informa-
tion on Operation of your new boat. Skip to page 24 for Operation.
2. IMPORTANT: Before using the product, be sure to read and
understand the Warnings on page 4-5.
3. IMPORTANT: When moving the Multisport™ 270, always lift and
set it down. DO NOT DRAG, as this can damage the product before
you get started. It is helpful to have an assitant available for launch-
ing and moving the craft while on land.
TEL: (509) 493-4938 FAX: (509) 493-4966
270 Owner's Manual
™
Back Keel
Slots
Back
Keel Retainer
for more info go to:
www.Aquaglide.net
21
