Preparing Sailing Harness; Attaching Sailing Rig - Aquaglide Multisport 270 Owner's Manual

B-4
4 - 5. Tie the uphaul rope to itself using a double half hitch or similar
secure, non-permanent knot, as shown in photos B4 & B5.
B-5
C. Preparing the Sailing Harness
1. DO NOT attach the sailing harness for windsurfing.
C-1
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
Multisport
C-2
2. Remove the bridle straps from each side of the hull.
3. Remove the forestay webbing strap from the tow fitting.
C-3
D. Attaching the Rig
D-1
1. To attach the rig ffor windsurfing, insert the mast base into the mast
step as show in photo D1.
TEL: (509) 493-4938 FAX: (509) 493-4966
270 Owner's Manual
™
Front
Mast Step
for more info go to:
www.Aquaglide.net
Mast Base
19
