Aquaglide Multisport 270 Owner's Manual page 20

D-2
Front
2. Connect the mast base to the mast step using the two integrated
straps and buckles. Take each strap through the corresponding mast
step connector and secure using the corresponding buckle. Once con-
nected, cinch both straps firmly.
3. Next, you are ready to attach the sailing rig. It may be helpful to have
an assitant available to steady the rig during this process. Lift the sailing
rig into position with the mast over the mast base and toward the front
of the hull. Slide the mast over the upper part of the mast base until it is
completely seated.
D-3
4. Secure the rig to the mast base using the strap at the foot of the sail.
Lead the strap around the catchment on the upper part of the mast base
then back to the buckle at the foot of the sail as show in photo D4 on
the following page. Tighten by pulling down on the sail while cinching
firmly on the sail strap. Repeat this several times until the sail can go no
farther.
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
20
D-4
5. Attach the lower part
of the uphaul strap to the
same catchment on the
mast base. Lead the free
end of the webbing strap
around the mast and
catchment, then back up to
the buckle part way up the
uphaul strap. Secure the
end of the webbing with the
buckle. The end result is
shown in photo D5.
TEL: (509) 493-4938 FAX: (509) 493-4966
D-5
Main Sheet/
Uphaul Strap
for more info go to:
www.Aquaglide.net
Front
Front
