B-16
16. Next, tie the Mainsheet/ Uphaul Strap to the back of the boom.
Thread the white rope at the top portion of the Mainsheet Strap through
the black rope loop at the back of the boom.
17. Take an additional turn around the black loop.
B-17
Main Sheet/
Uphaul Strap
18 - 19. Tie the white rope to itself using a double half hitch or similar
secure, non-permanent knot, as shown in photos B18 & B19.
B-18
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
10
Main Sheet/
Uphaul Strap
Main Sheet/
Uphaul Strap
B-19
C. Preparing the Sailing Harness
C-1
Front
1. Next, prepare the sailing harness. The first step is to install the bridle
straps. Photo C1 shows one bridle strap completed on the left (port) side
of the hull. Steps C2 through C11 are taken during initial setup, however,
for sailboat use, the bridle straps can be left on the hull indefinitely. For
windsurf, tow or kayak use, the bridle straps should be removed.
2. Locate and remove the two bridle straps from the sailing harness as
shown. The bridle straps have webbing and a clear tubing section.
C-2
Sailing Harness
TEL: (509) 493-4938 FAX: (509) 493-4966
Main Sheet/
Uphaul Strap
Bridle Strap
Shroud
Connection Points
Bridle Straps
for more info go to:
www.Aquaglide.net
Back
