2. Next, lead the opposite end of the rope through the eye splice as
shown in photo C2.
3. Pull the entire length of the tow rope through the eye splice and cinch
firmly.
D. Assembly Complete - Now What?
1. IMPORTANT: Before using the product, be sure to read and
understand the Warnings on page 4-5.
2. IMPORTANT: When moving the Multisport™ 270, always lift and
set it down. DO NOT DRAG, as this can damage the product before
you get started. It is helpful to have an assitant available for launch-
ing and moving the craft while on land.
VI. Assembly - Kayak
When using the Multisport™ 270 as a kayak, only the hull and keels are
used. Paddle is not included. Multisport™ Kayak Kit is an optional ac-
cessory. Detailed instructions on attaching the Kayak Kit are contained
in that package. The following steps outline the steps to be taken and
the points to note.
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672
Multisport
A. Preparing the Hull
1. Same as the steps for preparing the hull in sailboat mode located on
page 6.
B. Points to Note
1. Remove the bridle straps from each side of the hull.
B-1
2. Remove the forestay webbing strap from the tow fitting.
B-2
3. Install BOTH keels in the hull. Secure using the keel retainer.
B-3
TEL: (509) 493-4938 FAX: (509) 493-4966
270 Owner's Manual
™
Keel Retainer
for more info go to:
www.Aquaglide.net
23
