MAKERBOT REPLICATOR 2X DIAGRAMS
Fan Guards
1
Extruder Fans
2
Extruder Nozzles
3
Fan Bolts
4
Cartridge Heaters
5
Thermal Cores
6
Drive Blocks
7
Extruder Cable Mount
8
Motor Cable Connectors
9
Extruder Motors
10
Heat Sinks
11
Bar Mount
12
Spacers
13
Extruder Carriage
14
Extruder Arms
15
11
WELCOME
1
2
3
14
Front view of extruders
7
Angled view of extruders
CONTINUED
13
4
5
6
8
9
15
10
11
12
