- Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 2. Replace fuse only with the specified type and rating. 3. Do Not install the unit to close to a heat source. 4.
-
Page 4: Mechanical Specifications
Technical Features Part Numbers Fixture Flight Case 1100 - AXIS LED P-1100DUALCASE Mechanical Specifications 7” 9.25” Pan: 360° Tilt: 270° DMX Connectors: 3-pin XLR connectors 3.5” Thermal: Maximum ambient temperature 35° C Maximum surface temperature 80° C Mounting Points: 2 pairs of L-turn locks 9.5”... -
Page 5: Dmx-512 Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: 110V 50/60hz Connection Cable (USA) Cable (EU) International Brown... -
Page 6: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. - Page 7 Axis LED DMX profile-version 1.0 DMX Channel Function Description Value Pan course 0-255 Tilt Tilt course 0-255 Pan Fine Pan fine 0-255 Tilt fine 0-255 Tilt Fine Max speed (tracking mode) Max to min speed (vector mode) 1-244 Speed Changes...
-
Page 8: Main Control Menu
Main Control Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions including errors and diagnostics. The following will ex- plain each function and its options. -
Page 9: Cleaning And Maintenance
Cleaning and maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron- ics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 10 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
