1.2 Standard Specifications

Item
Document size
Effective scanning area
Guaranteed scanning precision
range *3
Document thickness
Optical resolution
Interpolated resolution
Main scanning system
Sub scanning system
Scanning speed *2
Scanning precision *3
Gradation
Threshold value
Color space
Sensor Total number of pixels
Output
Light source
Interface *4
Output
Rated power supply
Operating environment
Power consumption
External dimensions (approx.)
Weight (approx.)
If the document is a long-length document, the actual length that can be scanned is limited by the available
* 1
memory (hard disk or other data storage device) of the computer to which the scanner is connected, and also by
the grade of the medium being scanned.
CS610-UM-251-9370
CS610-11eN
ANSI E to ISO A4
Maximum width: 1092 mm; minimum width: 210 mm
1092 mm
Width: 1,066.8 mm (centered)
Length: 16 m
*1
If the thickness exceeds 1.5 mm, 762 mm (30 inches) maximum
841 mm x 1189 mm, maximum thickness 1.5 mm
600 dpi
From 50 to a maximum of 800 dpi, in
1-dpi increments
Contact image sensor system
Five A4 sensors in staggered arrangement
Document travel (sheet through) system
When the document thickness is 1.5 mm or less (400 dpi, A0)
Normal scan
Monochrome: 13 s
Gray scale: 25 s
8-bit color: 47 s
24-bit color: 47 s
When the document thickness is 1.5 mm to 20.32 mm (400 dpi, A0)
Normal scan
Monochrome: 34 s
Gray scale: 41 s
8-bit color: 45 s
24-bit color: 45 s
±0.1%, ±5 pixels
Monochrome: Bilevel, intermediate tones (dither, error diffusion)
Gray : 256 shades
Color: 8-bit, 24-bit
Automatic threshold setting by DSP in monochrome mode
sRGB compatible
25,200 pixels
Color: 42 bits/pixel
Grayscale: 14 bits/pixel
LED (RGB)
USB 2.0, Ethernet
Image data
100 to 120 VAC / 200 to 240 VAC ±10%, 50/60 Hz
Temperature: 10˚C to 35˚C;Humidity: 35% to 80% RH (no condensation)
135 VA or less (60 W or less) (6.3W or less in power-saving mode)
1205 mm (W) X 957 mm (H) X 650 mm (D) (including stand)
47 kg (including stand)
1-2
CS610-11eN-PRO
From 50 to a maximum of 9600 dpi, in
1-dpi increments
High-speed scan
Monochrome: 8 s
Gray scale: 22 s
8-bit color: 33 s
24-bit color: 33 s
High-speed scan
Monochrome: 34 s
Gray scale: 41 s
8-bit color: 40 s
24-bit color: 40 s
