Relion 2908GT Chassis Manual
IO=3F8h; IRQ=4; DMA;/
IO=3F8h; IRQ=3,4,5,7,9,10,11,12; DMA;/
IO=2F8h; IRQ=3,4,5,7,9,10,11,12; DMA;/
IO=3E8h;
DMA;/ IO=2E8h; IRQ=3,4,5,7,9,10,11,12;
DMA;.
Default setting is Use Automatic Settings.
Serial Port 2 Configuration
Use This Device
When enabled allows you to configure the serial port 2 settings. When set to Disabled, displays no
configuration for the serial port.
Options available: Enabled/Disabled. Default setting is Enabled.
Logical Device Settings:
Current:
Display the Serial Port 2 base I/O addressand IRQ.
Possible:
Configure Serial Port 2 base I/O addressand IRQ.
Option available:
Use Automatic Settings/
IO=2F8h; IRQ=3; DMA;/
IO=3F8h; IRQ=3,4,5,7,9,10,11,12; DMA;/
IO=2F8h; IRQ=3,4,5,7,9,10,11,12; DMA;/
IO=3E8h;
DMA;/ IO=2E8h; IRQ=3,4,5,7,9,10,11,12;
DMA;/
Default setting is Use Automatic Settings.
BIOS Setup
IRQ=3,4,5,7,9,10,11,12;
IRQ=3,4,5,7,9,10,11,12;
- 72 -
