Penguin Computing Relion 2908GT Technical Manual page 46

Relion 2908GT Chassis Manual
26 DIMM_P0_B0
27 DIMM_P0_B1
28 DIMM_P0_B2
29 CPU0
30 CPU1
31 PCIE_3
32 DIMM_P1_H2
33 DIMM_P1_H1
34 DIMM_P1_H0
35 DIMM_P1_G2
36 DIMM_P1_G1
37 DIMM_P1_G0
38 PCIE_4
39 BP_1
40 ATX2_2
41 ATX2_1
42 ATX2_3
43 FP_2
44 PMBUS_SEL
45 PCIE_2
46 DIMM_P1_F2
47 DIMM_P1_F1
48 DIMM_P1_F0
49 DIMM_P1_E2
50 DIMM_P1_E1
51 DIMM_P1_E0
52 PCIE_1
53 DIMM_P0_C0
54 DIMM_P0_C1
55 DIMM_P0_C2
56 DIMM_P0_D0
57 DIMM_P0_D1
58 DIMM_P0_D2
59 SSI_2X9P
60 CLR_CMOS
61 BAT
62 TPM
63 SW_RAID
64 S3_MASK
65 BIOS_WP
66 BIOS_PWD
67 ME_RCVR
68 BMC_FRB
69 BIOS_RCVR
Channel 2 slot 0 (for primary CPU)
Channel 2 slot 1 (for primary CPU)
Channel 2 slot 2 (for primary CPU)
Intel LGA2011 Socket R (Primary CPU)
Intel LGA2011 Socket R (Secondary CPU)
PCI-E slot 3 (x16 slot)
Channel 4 slot 2 (for secondary CPU)
Channel 4 slot 1 (for secondary CPU)
Channel 4 slot 0 (for secondary CPU)
Channel 3 slot 2 (for secondary CPU)
Channel 3 slot 1 (for secondary CPU)
Channel 3 slot 0 (for secondary CPU)
PCI-E slot 4 (x16 slot)
HDD back plane board header
8 pin power connector
8 pin power connector
4 pin power connector
Front panel hearder (secondary)
PMBus Power Select jumper
PCI-E slot 2 (x16 slot)
Channel 2 slot 2 (for secondary CPU)
Channel 2 slot 1 (for secondary CPU)
Channel 2 slot 0 (for secondary CPU)
Channel 1 slot 2 (for secondary CPU)
Channel 1 slot 1 (for secondary CPU)
Channel 1 slot 0 (for secondary CPU)
PCI-E slot 1 (x16 slot)
Channel 3 slot 0 (for primary CPU)
Channel 3 slot 1 (for primary CPU)
Channel 3 slot 2 (for primary CPU)
Channel 4 slot 0 (for primary CPU)
Channel 4 slot 1 (for primary CPU)
Channel 4 slot 2 (for primary CPU)
18 pin main power connector
Clear CMOS jumper
Battery socket
TPM module connector
Software RAID Key jumper
S3 Power On Select jumper
BIOS write protect jumper
Clearing Supervisor Password jumper
ME recovry jumper
Force to Stop FRB Timer jumper
BIOS recovery jumper
- 46 - Hardware Installation
