Relion 2908GT Chassis Manual
Chapter 3
3-1
Front View
No.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
System Appearance
Decription
Front panel LED and buttons
System fan (GPU78_FAN)
2.5-inch hard disk drive #1
2.5-inch hard disk drive #2
2.5-inch hard disk drive #3
2.5-inch hard disk drive #4
2.5-inch hard disk drive #5
2.5-inch hard disk drive #6
2.5-inch hard disk drive #7
2.5-inch hard disk drive #8
System fan (GPU34_FAN)
- 38 -
Hardware Installation
