Relion 2908GT Chassis Manual
3-3

Front Panel LED and Buttons

No. Name
Power button
1.
and LED
ID Button
2.
and LED
LAN1
3.
Activity LED
LAN2
4.
Activity LED
HDD
5.
Activity LED
System
6.
Status LED
7. Reset Button
3
4
5
6
7
Color Status
Green Solid On System is powered on.
Green Blink
N/A Off
Blue Solid On System identification is active.
N/A Off
Green
Solid On Link between system and network
Green Blink
N/A Off
Green
Solid On Link between system and network
Green Blink
N/A Off
Green Solid On HDD access
Green/ Blink
AMber Alternately
Green Solid On HDD access
Green Solid On Running or normal operation
Amber Solid On There is at least one sensor that has critical alter.
N/A Off
1
2
Description
System is in ACPI S1 state (sleep mode)
• System is not powered on or in ACPI S5
state (power off)
• System is in ACPI S4 state (hibernate
mode)
System identification is disabled.
Network access
Disconnect/Idle
Network access
Disconnect/Idle
HDD rebuilding
System is not ready.
Press the button to reset the system.
- 40 - Hardware Installation
