Relion 2908GT Chassis Manual
2-4
Installing the Heat Sink
Follow these instructions to install the heat sinks:
1.
Apply thermal compound evenly on the top of the CPU.
2.
Remove the protective cover from the underside of the heat sink.
3.
Place the heat sink(s) on top of the CPU and tighten the four positioning screws.
CPU0 and CPU1 use the different CPU heat sinks. Please see the following table for installing
the correct CPU heat sink.
CPU0
CPU1
- 19 -
Hardware Installation
