Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 4 mm diameter screws are enclosed in
the screw pack.
Screw Type B
Diameter (mm)
4
149.50 mm
14.04 mm
30
Length (mm)
25
242.04 mm
Tightening Screw
Allen Key
Allen Key
Tightening Screw
Washer Type
Large
Small
V
V
84.00 mm
