WXGA
If the projector is 50 cm from the screen, good image quality is possible for
image sizes around 100".
Note: Remind as below figure, the space of 166 cm height is
required when the projector is located at 50 cm distance.
Screen Size (Min zoom)
Desired
Distance
Diagonal
(cm)
(inch)
W (cm) x H (cm)
< A >
< B >
5
43
10
49
15
56
20
62
25
68
30
75
161 x 100
35
81
174 x 109
40
87
188 x 117
50
100
215 x 134
60
112
242 x 151
80
137
296 x 185
100
162
350 x 219
120
187
404 x 252
150
225
485 x 303
Zoom Ratio: 1.0 x
50 cm
Desired distance
A
100"
From base to
bottom of
image (cm)
< C >
93 x 58
72
106 x 67
82
120 x 75
93
133 x 83
103
147 x 92
113
124
134
145
166
186
228
270
312
374
C
B
15
Height:
166 cm
From
base to
bottom
of image
