Centurion BENINCA IT24N Installation Instructions Manual

Undeground swing gate operator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IT24N, BENINCA installation manual
I T 2 4 N
UNDERGROUND
SWING GATE
OPERATOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BENINCA IT24N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Centurion BENINCA IT24N

Summary of Contents for Centurion BENINCA IT24N

  • Page 1 IT24N, BENINCA installation manual I T 2 4 N UNDERGROUND SWING GATE OPERATOR...

  • Page 2: Company Profile

    50 countries worldwide CENTURION SYSTEMS (Pty) Ltd. reserves the right to make changes to the products described in this manual without notice and without obligation of CENTURION SYSTEMS (Pty) Ltd. to notify any persons of any such revisions or changes. Additionally, CENTURION SYSTEMS (Pty) Ltd.

  • Page 3: Table Of Contents

    Contents Mechanical setup page 1 Electrical setup page 2 Commissioning and handover page 2 page 3 IMPORTANT SAFETY INSTRUCTIONS Declaration of conformity page 5 General description page 6 page 7 Specifications Fuse protection page 9 Icons used in this manual page 9 page 10 Product identification...

  • Page 4: Mechanical Setup

    Mechanical setup These abbreviated instructions are for the experienced installer who needs a checklist to get a standard installation up and running in the minimum of time. Detailed installation features and functions are referred to later in this manual. Gather required tools and equipment page 11 Heed necessary site considerations page 12...

  • Page 5: Electrical Setup

    Electrical setup Mount controller enclosure and connect all wiring Commissioning and handover Commission system Carry out professional handover to client page 2...

  • Page 6: Important Safety Instructions

    IMPORTANT Safety Instructions ATTENTION To ensure the safety of people, it is important that you read all the following instructions. Incorrect installation or incorrect use of the product could cause serious harm to people. The installer, being either professional or DIY, is the last person on the site who can ensure that the operator is safely installed, and that the whole system can be operated safely.
  • Page 7 Always check the obstruction detection system, and safety devices for  correct operation Centurion Systems does not accept any liability caused by improper  use of the product, or for use other than that for which the automated system was intended This product was designed and built strictly for the use indicated in ...

  • Page 8: Declaration Of Conformity

    1. Declaration of conformity Manufacturer: Automatismi Benincà spA Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia Herewith declares that: the operator for hinged gates model DU.IT24N is intended to be incorpored into machinery or to be assembled with other machinery to constitute ...

  • Page 9: General Description

    2. General description The IT24, Beninca is an underground swing gate operator designed for domestic and light- industrial applications where the operator is hidden from view. It is also useful in applications where the gate swings hard up against its side wall leaving absolutely no space to mount a traditional above-the-ground unit.

  • Page 10: Specifications

    3. Specifications Gearbox and DC motor assembly * Output drive arm, mechanical release and drive shoe not shown All dimensions shown in millimeters FIGURE 1. GEARBOX AND MOTOR DIMENSIONS Foundation box All dimensions shown in millimeters FIGURE 2. FOUNDATION DIMENSIONS page 7...

  • Page 11: Technical Specifications

    400 x 400 x 250mm Controller housing 480 x 320 x 150mm Can operate off a solar supply, consult Centurion Systems for assistance Can increase battery capacity for longer standby times Based on 25°C ambient temperature and unit not in direct sunlight...

  • Page 12: Fuse Protection

    Allowable gate mass 2.0m 3.5m Leaf width 2.5m 3.0m 4.0m 550kg 400kg Leaf mass 500kg 350kg 450kg External electric lock must be fitted Allowable wind loading Leaf width 2.0m 2.5m 3.0m 3.5m 4.0m Maximum wind speed (1.8m high gate, 25% coverage) 80km/h 65km/h 50km/h...

  • Page 13: Product Identification

    5. Product identification Drive shoe 9. Manual release mechanism Drive assembly ball bearing 10. Gearbox drive arm Output drive arm 11. 24V DC motor and sealing O ring Linkage arm 12. Gearbox housing Gearbox output shaft and secondary stage 13. Foundation box cover plate wormwheel gear 14.

  • Page 14: Required Tools And Equipment

    6. Required tools and equipment Allan key – 5mm Crimping tool and pin lugs Duct tape Electric drilling equipment Hacksaw Hammer Measuring tape Pick Pliers Ratchet and extension with a 7mm and 19mm socket Screwdriver – 3.5mm flat; large star; small star Side cutters Spade Spanner –...

  • Page 15: Preparation Of Site

    7. Preparation of site General considerations for the installation Always recommend the fitment of additional safety equipment such as safety edges and safety  beams, for additional protection against entrapment or other mechanical risks  Check that no pipes or electrical cables are in the way of the intended installation Check that it is possible to mount the foundation box directly beneath the gate hard up against ...

  • Page 16: Cabling Requirements

    8. Cabling requirements FIGURE 4. CABLING REQUIREMENTS Legend 1a. 220V AC mains cable via double pole mains isolator switch (3 core LNE 1.5mm SWA ) or 1b. Low voltage cable from transformer (34V secondary @ 800mA) to battery charger (2 core + earth 1.5mm² Norsk ) 2.
  • Page 17 All cables must be routed in conduit unless underground cable is being used  Mains isolator must be less than 1m from the operator  Safety beams are always recommended  page 14...

  • Page 18: Operator Installation

    9. Operator installation To simplify the installation process, it is recommended that the existing gate is removed from the pillar before proceeding. Foundation box installation As the foundation box is liable to fill with water during rainfall, it is critical that an adequate drainage system is prepared.
  • Page 19 2. Dig a hole for the foundation box - the size of the hole being adequate to securely anchor the foundation box taking into consideration:  Weight of the gate resting on the foundation box  Condition of the soil around the foundation box 3.
  • Page 20 5. Cover the drainage holes on the inside with duct tape. FIGURE 10 Line of gate hinges 6. Insert the foundation box into the hole. Ensure the box is placed in a horizontal Seal between casing and position, with the casing pivot at exactly 90° conduit to the base, and perfectly aligned with the To controller...
  • Page 21 9. As soon as the previous step is completed, determine the position on either side of the foundation box to which the drainage holes will lead. Prepare drainage shafts as follows: Foundation box  Dig drainage shafts next to the concrete foundation adjacent to the drainage holes of the foundation box Drainage hole...
  • Page 22 2. Assemble the drive arm onto the gearbox just above the limit switch cam disc, firmly tightening the cap screw to a maximum torque of 45Nm. FIGURE 16 3. Orientate the gearbox and motor assembly according to the mounting configuration (standard or inside).
  • Page 23 4. Join the linkage arm to the drive arm. FIGURE 18 5. Pre-assemble the drive assembly consisting of the operator output drive arm, drive shoe and manual release mechanism. FIGURE 19 6. Weld this to the underside of the gate frame, ensuring that the pivot on this assembly is perfectly aligned with the top hinge of the gate.
  • Page 24 7. Re-install the gate ensuring that the drive assembly ball bearing is placed in the cup of the foundation box pivot before lowering the drive assembly onto the pivot. FIGURE 21 8. Join the linkage arm together with the drive assembly, as mentioned in point four on the pervious page.
  • Page 25 Open endstop 3. It is possible to use the internal limit switch to stop the gates in the open position. 4. Alternatively mechanical endstops can be used, mounted where each leaf swings to, in the open position. Microswitch 5. The limit switch disc should already have group been mounted onto the motor’s output shaft at an earlier stage.

  • Page 26: Electrical Setup

    10. Electrical setup 1. Always check that the circuit breaker in the electrical panel is in the OFF position, and that all high voltage circuits (more than 42.4V) are completely isolated from the mains supply before doing any work. 2. Ensure that all low voltage systems (less than 42.4V) are suitably protected from damage, by disconnecting all sources of power such as chargers and batteries before doing any work.
  • Page 27 3. Ensure that both the controller and the charger are effectively earthed for improved lightning protection. FIGURE 28 FIGURE 28 • Earth system at the gate using a copper earth spike. • Ensure that the system is connected to ESCOM or main earth. 4.

  • Page 28: Wiring Diagram For Safety Beams

    Wiring diagram for safety beams Receiver beam Receiver beam inside outside Transmitter Transmitter beam beam inside outside FIGURE 30 Although this terminal is marked as 12V the controller is modified to supply 24V DC  Although these terminals are marked as 15V the controller is modified to be ...

  • Page 29: Wiring Diagram For Other Accessories

    Wiring diagram for other accessories Radio receiver TRIGGER (Note 1) STATUS LED Gate lock (Note 2) (Note 3) Battery Pillar light 220V FIGURE 31 1. Connect a single pole, single throw switch between terminal 5 and common for external autoclose, or select switch 1 “ON” 2.

  • Page 30: Wiring Diagram For Motors And Open Limits

    Wiring diagram for motors and open limits FIGURE 32 Although this terminal is marked as 12V the controller is modified to supply 24V DC  Although these terminals are marked as 15V the controller is modified to be  supplied by 30V AC Only connect the limit switch that will be activated in the open position ...
  • Page 31 5. Check that the 24V battery supply is connected to the controller. Ensure that the battery polarity is correct. 6. Switch on the mains supply (via isolator). 7. Check that the green charger LED on the controller lights up. Control card setup 8.
  • Page 32 9. If Autoclose has been selected, set Autoclose timer potentiometer to suit. Clockwise increases time (range 5-30 seconds). It is always recommended to have infrared safety beams fitted when using the Autoclose feature. FIGURE 36 Set motor polarity 10. Identify status LED, which will give information on gate status, whether gate is open, closed, etc.
  • Page 33 Collision sensitivity adjustment 13. Adjust the sensitivity on the controller such that the gate(s) will open and close reliably, but not cause damage to persons or objects in the path of the gate(s). 14. The motor will just stop when the gate(s) hits an obstruction while opening or closing.
  • Page 34 18. Adjust the respective potentiometer depending on whether the gate was opening or closing, clockwise if the gate stopped too easily or anti-clockwise if the gate was hard to stop. FIGURE 42 page 31...

  • Page 35: Controller Features

    14. Controller features Inherent safety features Safety (Collision sensitivity) If the gate is obstructed, the internal collision circuitry will activate the gate whether opening or closing to just stop. The response of the system to a collision will vary according to the sensitivity level that has been set.
  • Page 36 Standard Mode via gate trigger  When stationary, a trigger impulse on TRG will cause the gate to either open or close. While the gate is moving, a trigger impulse on TRG will stop the gate. A third impulse on TRG will cause the gate to reverse its direction of travel, i.e.
  • Page 37 Outputs with associated features Gate status LED (LED)  External gate status indicator. This output provides a low current drive to light up a LED which can be used to indicate the gate status remotely. For instance if the gate is not visible from the intercom handset inside the house, which is used to communicate with a visitor at the gate and operate the gate, an LED fitted to the intercom, wired to the LED output on the gate controller, will give the necessary feedback about the status of the gate.

  • Page 38: Description Of Terminal Functions

    15. Description of terminal functions Pedestrian Opening input. (A normally-open potential-free input). Momentarily connecting this input to COM will cause the master gate to open to the pedestrian open position. For more information refer to the pedestrian feature under Section 13. Holiday Lockout.
  • Page 39 Open limit contact for slave motor. The contact must be normally-open. The contact is wired between this point and common. Closed limit contact for slave motor. The contact must be normally- open. The contact is wired between this point and common. Not used if a closed mechanical endstop is used to stop the gate.

  • Page 40: Diagnostics

    16. Diagnostics Diagnostic LEDs The CP77 controller has a series of diagnostic LEDs which indicate the state of the inputs. PED - red On when the pedestrian signal is present SP1 - red On when the LCK/STP input is activated TRG - red On when a trigger signal is present SP2 - red...

  • Page 41: Gate Status Led

    Gate status LED Status - red This LED indicates the state of the gate as per table below FIGURE 44 Gate is closed Gate is partially or fully open Continuous slow flash Gate is opening Continuous fast flash Gate is closing One flash every two seconds Pillar light override is activated Two flashes every two seconds No mains present...

  • Page 42: Manual Release Operation

    17. Manual release operation Hinge open dust flap Dust flap 1. Hinge open the dust flap, insert key into lock and give 1/8 turn clockwise. Insert key and turn FIGURE 45 2. Pull manual release sideways to disengage gate leaf from operator. If an external lock is fitted this must also be released.

  • Page 43: Installation Handover

    Centurion Systems (Pty) Ltd. does not accept any liability caused by improper use, of the product, or for use other than that for which the automated system was designed.
