outsrc (output signal source)

This command may be used as a query to read the
output signal source status, or as an update to set the
status. The output channel is specified by using the
address syntax. Addresses must be in the range 1 to 4.
The data type is integer, unless the channel address is
wildcarded, in which case the data type is an array of
integer of size 4. The following values are allowed:
0 - 11 means that the output channel is fed by one of
the 12 final mixes exposed by the Master DM
series automixer in the system. Note that a zero
based index is used to specify the mix.
32 means that the output channel is fed by Expan-
sion Bus number 1 (normally used with a
DMTH4 telephone hybrid)
33 means that the output channel is fed by Expan-
sion Bus number 2 (normally used with a
DMTH4 telephone hybrid)
64 means that the output channel is fed by a 20Hz
to 20kHz 0 dBu pink noise source
65 means that the output channel is fed by a 300Hz
to 20kHz 0 dBu pink noise source
96 means that the output channel is fed by a 0 dBu,
1 kHz tone source
In the case of an update with the channel address
wildcarded, the value 99 may be used to indicate that a
particular output source is to remain unchanged by the
command.
Examples:
REQUEST
QUERY
outsrc(3)?<CR>
QUERY
outsrc(*)?<CR>
UPDATE
outsrc(2)=2<CR>
UPDATE
outsrc(*)=
{0,0,1,99}<CR>
56
RESPONSE
OK 0<CRLF>
OK {0,0,1,2}<CRLF>
OK<CRLF>
OK<CRLF
