DM84 Digital Matrix Processor
Name
Programmable output status indicators
Channel activity controls
Rear Panel Ctrl Copy/Paste
42
Description
• Run a Macro on Close/Open - Active when there is a contact closure on programmable
input.
• Momentary Unmute Inputs (PTT) - Active when the audio inputs controlled by the program-
mable input are unmuted.
• Monitor Active Preset (AP) This function monitors the active preset and activates the
programmable output if one of the specified presets becomes active (is recalled from
nonvolatile memory). This function is configured by selecting one or more presets to be
monitored.
To finish the setup, the programmable output invert status may be set using the Invert
checkbox. If inverted, a programmable output will behave in a manner opposite to that de-
scribed above in the function descriptions.
These are lit red when the corresponding programmable output becomes active (conducting
to ground).
When the Monitor Input Ch Activity function is assigned to a programmable output, these are
used to set the parameters controlling the time response of the function:
• input qualification time - the length of time that an audio input must be dominant before
the programmable output is activated.
• output hold time - the length of time after an audio input has ceased to be dominant
before the programmable output is deactivated.
The group consists of two numerical controls:
• Input Qualification Time - The qualification time value is displayed here and can be
adjusted from 0.1 to 25.5 seconds.
• Output Hold Time - The hold time value is displayed here and can be adjusted from 0.1 to
25.5 seconds. The value may be changed in the same manner as the Input Qualification
Time control.
The entire group of rear panel control settings can be copied and pasted into another preset.
This can save a lot of time when a common rear panel setup needs to be duplicated in
multiple presets.
