Lectrosonics DM84 Reference Manual page 20

DM84 Digital Matrix Processor
4. Enter the file name for the update in the Path to
Update File field or click the browse button next to
the filename field to locate the update file. If the
browse button is clicked, the Select DM84 update
file dialog opens. If the file name was entered
manually, click Next.
If the browse button was clicked, select the update
file from the list and click Open to transfer that
filename to the Path to Update File field. Then
click Next.
5. Click Start Update to begin the firmware update.
20
The update is made in two stages, an update of the
DM DSP firmware, followed by an update of the
controller firmware. The progress bar indicates the
status of each update stage.
