- Page 1 PW 5M-7M-9M-11M Instructions for installation and use English More documents on: www.zodiac-poolcare.com H0357900.D - 2014/03...
- Page 2 • Read this notice carefully before installing, maintaining or repairing this appliance! • The symbol indicates important information that you must take into account to avoid the risk of damage to persons or the appliance. • The symbol indicates useful information as an indication. Warning •...
-
Page 3: Table Of Contents
Contents 1. Information before installing ........................3 1.1 General delivery terms and conditions ...................... 3 1.2 Content ................................3 1.3 Technical specifications ..........................3 2. Installation ............................... 3 2.1 Selection of the location ..........................3 2.2 Installing the appliance ..........................3 2.3 Hydraulic connections .......................... -
Page 4: Information Before Installing
11.82 * with surrounding air temperature at 15°C and pool water at 24°C, humidity level 70% • Operating temperatures: from 7 to 32°C air and up to 32°C water (30°C with Zodiac® Easy Connect) 2. Installation Do not lift the appliance using the casing, handle it from the base. -
Page 5: Hydraulic Connections
2.3 Hydraulic connections VE: water intake valve VB: by-pass valve VS: water output valve * minimum distance 9M 11M Test pressure Service pressure Load loss Water flow optimum m³/h minimum Water flow m³/h maximum* * rate not to be exceeded Follow the hydraulic connection direction (see §... -
Page 6: Use
• Loose terminals can cause the terminal block to heat and lead to the warranty being voided. • It is imperative to connect the appliance to an earth rod. • Risk of electric shocks inside the appliance. • Only a qualified and experienced technician is authorised to wire inside the appliance. •... -
Page 7: Checks To Carry Out Once The Appliance Is Running
• Possibility of reading the water temperature: when water is flowing through the heat pump, press flashes 10 seconds then the fixed temperature set point is displayed, • Possibility of locking the keyboard: - Keyboard lock: press at the same time for 3 seconds: appears for 3 seconds, then: - Unlocking the keyboard: press at the same time for 3 seconds:... -
Page 8: Recycling
• During the maintenance phase make sure there are no traces of corrosion or oil stains around the refrigerating components. • Before any operations on the refrigerating circuit it is imperative to shut down the appliance and to wait a few minutes before fitting temperature or pressure sensors. -
Page 9: Faq
6. Registering the product Register your product on our website: be the first to be informed of new Zodiac® products and special offers, help us to constantly improve our product quality. Europe & Rest of the World www.zodiac-poolcare.com America www.zodiacpoolsystems.com... - Page 10 Electric diagram PW 5M-7M-9M PW 11M L-N-PE Power supply 230V-1N-50Hz H0357900.D - EN - 2014-03...
- Page 11 Digital display Fan relay Earth Auxiliary pump relay Compressor capacitor Complementary relay Fan capacitor Compressor Auxiliary pump capacitor Flow rate controller Auxiliary pump High pressure switch Auxiliary pump connector Low pressure switch Water temperature sensor Auxiliary pump Air temperature sensor Fuse Defrost sensor KM1 Compressor relay...
- Page 12 Votre revendeur / your retailer Pour plus de renseignements, merci de contacter votre revendeur. For further information, please contact your retailer. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
