Matrix T5X-07 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

T 5 x - 0 7 T r e a d m i l l
S e r V i C e m a N U a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T5X-07 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix T5X-07

Summary of Contents for Matrix T5X-07

  • Page 1 T 5 x - 0 7 T r e a d m i l l S e r V i C e m a N U a l...

  • Page 2: Table Of Contents

    Table of CoNTeNTS CHaPTer 1: Serial NUmber loCaTioN ..............CHaPTer 2: imPorTaNT SafeTy iNSTrUCTioNS Before Getting Started ....................2 Read and Save These Instructions ................3 Electrical Requirements .................... 4 CHaPTer 3: PreVeNTaTiVe maiNTeNaNCe Recommended Cleaning Tips ................... 5 Check for Damaged Parts ..................5 Care and Maintenance Instructions ................
  • Page 3 Table of CoNTeNTS 9.15 Handlebar Service ...................... 45 9.16 Emergency Stop Switch Replacement ............... 46 9.17 Heart Rate Board Replacement ................47 9.18 Blower Motor Replacement ..................48 9.19 Overlay Replacement ....................49 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.1 Treadmill Specifications .....................

  • Page 4: Chapter 1: Serial Number Location

    CHaPTer 1: Serial NUmber loCaTioN 1.1 Serial NUmber loCaTioN frame serial number location console serial number location...

  • Page 5: Before Getting Started

    CHaPTer 2: imPorTaNT SafeTy iNformaTioN 2.1 before GeTTiNG STarTed This treadmill is intended for commercial use. To ensure your safety and protect the equipment, read all instructions before operating the Matrix Treadmill. Place the treadmill on a level and stable surface away from direct sunlight. The intense UV light can cause discoloration on the plastics. Locate your treadmill in an area with cool temperatures and low humidity.

  • Page 6: Read And Save These Instructions

    When using an electrical product, basic precautions should always •   D onotusetheequipmentinanywayotherthandesignedorintended be followed including the following: by the manufacturer. It is imperative that all Matrix Fitness System's equipment is used properly to avoid injury. daNGer: To reduce the risk of electric shock: Always unplug this equipment from the electrical outlet immediately after using and • Keephandsandfeetclearofmovingpartsatalltimestoavoidinjury.

  • Page 7: Electrical Requirements

    CirCUiT / eleCTriCal reqUiremeNT iNfo All Matrix treadmills require the use of a 20 amp "dedicated circuit" with a non-looped (isolated) neutral / ground for the power requirement. Quite simply this means that each outlet you plug your treadmill into should not have anything else running on that same circuit. The easiest way to verify this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time.

  • Page 8: Chapter 3: Preventative Maintenance

    3.2 CHeCk for damaGed ParTS do NoT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems. maiNTaiN labelS aNd NamePlaTeS. Do not remove labels for any reason. They contain important information. If unreadable or missing, contact Matrix Fitness Systems for a replacement at 866-693-4863 or www.matrixfitness.com.

  • Page 9: Care And Maintenance Instructions

    Matrix web site at www.matrixfitness.com. daily maiNTeNaNCe iTemS 1) Clean the entire machine using water and mild detergent such as "Simple Green", or other Matrix approved solutions (cleaning agents MUST be alcohol and ammonia free).

  • Page 10: Auto Calibration Procedure

    CHaPTer 3: PreVeNTaTiVe maiNTeNaNCe 3.4 aUTo CalibraTioN iNSTrUCTioNS 3.5 aliGNiNG aNd TeNSioNiNG THe rUNNiNG belT Run Auto Calibration to calibrate incline after assembly and after After placing the treadmill in the position it will be used, the belt replacing any electronic component. must be checked for proper tension and centering.

  • Page 11: Console Description

    CHaPTer 4: CoNSole oVerlay aNd WorkoUT deSCriPTioN 4.1 CoNSole deSCriPTioN WorkoUT keyS: Simple program view and selection buttons. Press the Fitness Test button to cycle through available tests. qUiCk STarT / Go: One touch Start and Quick Start. eNTer: To confirm each program setting. UP / doWN iNCliNe: Easy information and incline selection.

  • Page 12: Manual Workout Operation

    4.3 oPeraTiNG leVel baSed ProGramS Your Matrix T5x-07 Treadmill offers a variety of level-based workouts to challenge users of all fitness levels. The following information will briefly explain the workouts and how to program the treadmill for each workout selection.

  • Page 13: Heart Rate Control Workout Operation

    7)PressGOorQUICKSTARTtobegintheworkout. 4.5 fiTNeSS TeST WorkoUT oPeraTioN Your Matrix T5x-07 Treadmill offers a variety of fitness tests - the Gerkin Firefighter Protocol, the Wellness Fitness Initiative (WFI), the Army, Navy, USMC, and USAF as well as the Physical Efficiency Battery (PEB).
  • Page 14 CHaPTer 4: CoNSole oVerlay aNd WorkoUT deSCriPTioN 4.5 fiTNeSS TeST WorkoUT oPeraTioN - CoNTiNUed SUb maximal Treadmill eValUaTioN CardioVaSCUlar fiTNeSS PerCeNTileS CoNVerSioN Table males: Vo2 max (ml/kg/min) 0-29 30-39 40-49 50-59 Stage Time Converted Vo2max >58.8 >58.9 >55.4 >52.5 1:00 31.15 SUPERIOR 1:15...

  • Page 15: Chapter 5: Manager Mode

    CHaPTer 5: maNaGer mode 5.1 USiNG maNaGer mode To enter Manager Mode, press & hold INCLINE DOWN and SPEED DOWN at the same time for 3-5 seconds until Manager Mode appears on the display. 2) To enter the Manager Mode, press ENTER once Manager Mode appears on the display.

  • Page 16: Chapter 6: Engineering Mode

    CHaPTer 6: eNGiNeeriNG mode 6.1 USiNG eNGiNeeriNG mode 1. To enter Engineering Mode, hold the INCLINE DOWN and SPEED DOWN keys for three seconds until Manager Mode appears on the middle LED dis- play. 2. Press any UP arrow key and Engineering Mode will appear on the display. 3.

  • Page 17: Chapter 7: Service Mode

    CHaPTer 7: SerViCe mode 7.1 USiNG SerViCe mode 1. To enter Service Mode, hold the INCLINE DOWN and SPEED DOWN keys for three seconds until Manager Mode appears on the middle LED display. 2. Press any DOWN arrow key and Service Mode will appear on the display. 3.

  • Page 18: Chapter 8: Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGram...
  • Page 19 CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGramS digital Communication Wire UCb little board Wire...
  • Page 20 CHaPTer 8: TroUbleSHooTiNG 8.1 eleCTriCal diaGramS Hand Pulse Sensor Wire Hand Pulse Wire...

  • Page 21: Motor Control Board (Mcb) Led Instructions

    CHaPTer 8: TroUbleSHooTiNG 8.2 mCb led iNSTrUCTioNS refereNCe deSCriPTioN deSiGNaTor Indicates if the digital communication is working normally between the console and the MCB. Blinking = Normal. RS485 DSP2 Off = Fault Indicates if the console is working normally. Blinking - Normal. Light = MCU Fault.

  • Page 22: Mcb Wiring

    CHaPTer 8: TroUbleSHooTiNG 8.3 mCb WiriNG Tb1 - aC motor Cable Socket Tb2 - input Power Cable Socket J9 - inside fan Cable Socket J10 - digital Communication Cable Socket J12 - elevation motor Cable Socket J16 - external fan Cable Socket...

  • Page 23: 0140 / 01A0 / 01A2 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.4 0140 / 01a0 / 01a2 error TroUbleSHooTiNG error meSSaGeS 0140 / 01a0 / 01a2 1) sYmPtom: a. 0140 - Incline motor operation failed. b. 01A0 - Incline motor disconnected. c. 01A2 - Incline motor is detected in the reverse of the position indicated by the potentiometer. 2) solution a.

  • Page 24: 01A8 / 02B6 / 02B7 / 02B8 Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.6 01a8 / 02b6 / 02b7 / 02b8 error TroUbleSHooTiNG error meSSaGe 01a8 / 02b6 / 02b7 / 02b8 1) sYmPtom: a. 01AB - Motor over current. b. 02B6 - Speed up is overcurrent. c. 02B7 - Speed down is overcurrent. d.

  • Page 25: 02Ad Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.8 02ad error TroUbleSHooTiNG error meSSaGe 02ad 1) sYmPtom: a. MCB is over temperature. 2) solution: a. Check to see that both fans are operating (there is a fan mounted to the MCB itself as well as an external fan). Also check the connection of the fans at the MCB (Figure A).

  • Page 26: 02B9 / 02Ba / 02Bd Error Troubleshooting

    CHaPTer 8: TroUbleSHooTiNG 8.10 02b9 / 02ba / 02bd error TroUbleSHooTiNG error meSSaGe 02b9 / 02ba / 02bd 1) sYmPtom: a. 02B9 - The inner memory IC data write error. b. 02BA - The inner memory IC data read error. c.

  • Page 27: Troubleshooting - No Power To The Console

    CHaPTer 8: TroUbleSHooTiNG 8.12 TroUbleSHooTiNG - No PoWer To THe CoNSole PoWer SWiTCH iS oN, bUT THe CoNSole HaS No diSPlay 1) SymPTom: a. The unit is not getting power from the outlet. b. The MCB is not getting power from the power receptacle. c.

  • Page 28: Troubleshooting - Heart Rate Issues

    HR handlebar). If the ohm reading is correct, your issue is not with the HR grip / HR wire portion of the HR system. b. Perform a continuity test on the treadmill console (see Service Bulletin - Continuity Test on Matrix Treadmills).

  • Page 29: Troubleshooting - Speed Shown Is Higher Than Belt Speed

    2) SolUTioN: a. Perform an amp draw on the incoming power (see Field Work Instruction - Running an Amp Draw on Matrix Treadmills). b. If the amp draw is too high regardless if a user is present or not, the issue is likely with the drive system (drive belt or motor).

  • Page 30: Chapter 9: Part Replacement Guide

    CHaPTer 9: ParT rePlaCemeNT GUide 9.1 moTor CoVer aNd loWer SHroUd remoVal 1) The motor cover is split into two pieces (called the motor cover and lower shroud 2) Remove the 2 screws holding motor cover to the frame (Figure A ). 3) Pull up on the rear of the motor cover to release the Velcro, and remove the motor cover (Figure B).

  • Page 31: Rear Roller Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.2 rear roller rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove one of the end caps using a Phillips screwdriver (Figure A). 3) Remove both roller adjustment screws using an 8 mm Allen wrench (Figure B). fiGUre a fiGUre b 4) Remove the roller from the running belt (Figures C &...

  • Page 32: Deck Removal

    CHaPTer 9: ParT rePlaCemeNT GUide 9.3 deCk rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Remove the rear roller as outlined in Section 9.2. 3) Remove the four deck screws using a 5 mm Allen wrench (Figure A). fiGUre a 4) Remove the deck from the running belt (Figures B &...

  • Page 33: Deck Cushion Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.4 deCk CUSHioN rePlaCemeNT 1) Remove the deck as outlined in Section 9.3. 2) Holding the bolt with a 5 mm Allen wrench, loosen the nut with a 13 mm socket (Figure A & B). fiGUre a fiGUre b 3) For the rear cushion, hold the cushion and remove the 13 mm nut (Figure C).

  • Page 34: Front Roller Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.5 froNT roller rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Using a hook or loop of wire, remove the spring from the drive belt tensioner. The tensioner should now pivot away from the drive belt (Figures A &...

  • Page 35: Running Belt Removal

    CHaPTer 9: ParT rePlaCemeNT GUide 9.6 rUNNiNG belT remoVal 1) Remove the motor cover as outlined in Section 9.1. 2) Remove the rear roller as outlined in Section 9.2. 3) Remove the deck as outlined in Section 9.3. 4) Remove the front roller as outlined in Section 9.5. 5) Remove the running belt and replace with a new belt (Figures A &...

  • Page 36: Side Rail Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.7 Side rail rePlaCemeNT 1) Remove the end cap using a Phillips screwdriver (Figure A). 2) Loosen the four screws under the frame using a 5 mm Allen wrench (Figure B). fiGUre a fiGUre b 3) Slide the rail off the back of the treadmill (Figures C &...

  • Page 37: Motor Control Board (Mcb) Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.8 moTor CoNTrol board (mCb) rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the motor cover as outlined in Section 9.1. 3) Cut any wire ties that are secured to the MCB panel. 4) Disconnect wires from the MCB - five total connections.

  • Page 38: Motor Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.9 moTor rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the motor cover as outlined in Section 9.1. 3) Release the drive belt tensioner as outlined in Section 9.5. 4) Disconnect the motor power cable from the MCB (Figure A).

  • Page 39: Drive Belt Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.10 driVe belT rePlaCemeNT 1) Remove the motor cover as outlined in Section 9.1. 2) Release the drive belt tensioner from drive belt as outlined in Section 9.5. 3) Remove the front roller screw on the drive belt side and loosen the screw on the opposite side (Figure A). fiGUre a 4) Lift the roller and remove the old drive belt (Figure B).
  • Page 40 CHaPTer 9: ParT rePlaCemeNT GUide 9.11 iNCliNe moTor rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Lift the treadmill and support it so that the front wheels are off the floor, or the unit may be tipped on its side (Figure A). fiGUre a fiGUre b 3) Remove the clip from the pin attaching the incline motor to the rack (Figure B &...

  • Page 41: Incline Motor Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.11 iNCliNe moTor rePlaCemeNT - CoNTiNUed 4) Disconnect the incline motor power cable from the MCB (Figure D). 5) Disconnect the pin from the incline motor (Figure E). fiGUre d fiGUre e 6) Lift the incline motor away from the treadmill (Figure F). 7) Reverse Steps 1-6 to install a new incline motor.

  • Page 42: Console Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.12 CoNSole rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the back cover of the console (Figure A). 3) Disconnect the console cable connectors (Figure B). fiGUre a fiGUre b 4) Remove the six 6 mm screws from underneath the console.

  • Page 43: Console Mast Arm Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.13 CoNSole maST arm rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12. 3) Take off the cup holder from the right side of the treadmill (Figure A). 4) Use a 6 mm Allen wrench to remove one screw and take off the plastic hand rail (Figure B).
  • Page 44 CHaPTer 9: ParT rePlaCemeNT GUide 9.13 CoNSole maST arm rePlaCemeNT - CoNTiNUed 7) Remove the screws holding the console frame to the mast arms with a 6 mm Allen wrench in the openings with arrows (Figure H). 8) Lift the frame from the mast arms and set it aside (Figure I). fiGUre H fiGUre i 9) Use a 6 mm Allen wrench to remove the lower mast arm mounting screws (Figure J).
  • Page 45 CHaPTer 9: ParT rePlaCemeNT GUide 9.14 CoNSole Cable rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12. 3) Take off the cup holder from the right side of the treadmill (Figure A). 4) Use a 6 mm Allen wrench to remove one screw and take off the plastic hand rail (Figure B).

  • Page 46: Console Cable Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.14 CoNSole Cable rePlaCemeNT 6) Cut the wire ties and begin to un-thread the wire harness (Figures F & G). . fiGUre f fiGUre G 7) Remove the spiral protective wrap from the top and bottom portions of the wire harness (Figures H & I). fiGUre H fiGUre i...
  • Page 47 CHaPTer 9: ParT rePlaCemeNT GUide 9.14 CoNSole Cable rePlaCemeNT - CoNTiNUed 8) Attach a pulling wire to the top of the defective console cable (Figure J). 9)Slowlyremovethedefectiveconsolecablestartingatthebottomofthemachineandpullingitdowntothemotorcompartment(FigureK). fiGUre J fiGUre k 10) Connect the new console cable at the motor tray - 3 connections total. Figures L & M show 2 of these connections, the 3rd is the coax cable.

  • Page 48: Handlebar Service

    CHaPTer 9: ParT rePlaCemeNT GUide 9.15 HaNdle bar SerViCe 1) Turn off power and disconnect the cord from the machine. 2) All items on the handle bar are removed using a Phillips screwdriver from the underside of the bar. 3) Once the screws are removed, lift the part carefully and disconnect any wire connections. 4)ReplacepartsasneededonhandlebarincludingtheQuickStartKeyandtheHeartRateGripPlates(FiguresA-F). fiGUre a fiGUre b...

  • Page 49: Emergency Stop Switch Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.16 emerGeNCy SToP SWiTCH rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12. 3) Use a Phillips screwdriver to remove two screws, one from each side of the red button (Figure A). 4) Lift the button from bracket by pulling one side out at a time (Figure B).

  • Page 50: Heart Rate Board Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.17 HearT raTe board rePlaCemeNT 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12. 3) The Heart Rate Board is located in front of the red Emergency Stop button (Figure A). 4) Disconnect the wires from each side of the Heart Rate Board (Figure B).

  • Page 51: Blower Motor Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.18 bloWer moTor remoVal 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12. 3) Lay the console face down and remove the four screws using a Phillips screwdriver (Figure A). 4) The console shell will now separate.

  • Page 52: Overlay Replacement

    CHaPTer 9: ParT rePlaCemeNT GUide 9.19 oVerlay rePlaCemeNT note: The instructions below are for console overlays / keypads replacement, but the procedure is the same regardless of where the overlay / keypad. 1) Turn off power and disconnect the cord from the machine. 2) Remove the console as outlined in Section 9.12.
  • Page 53 CHaPTer 9: ParT rePlaCemeNT GUide 9.19 oVerlay rePlaCemeNT - CoNTiNUed 8) Push the overlay ribbon cable through the hole in the console and plug it in (Figure F). 9) Match the overlay to the cutout on the console (Figure G). fiGUre f fiGUre G 10) Press down on the corners of the overlay to keep it in place, then remove the protective film (Figure H &...

  • Page 54: Chapter 10: Treadmill Specifications And Assembly Guide

    ULTIMATEDECK™CUSHIONINGSYSTEM INCLINE RANGE 0-15%(1,300LB/589.7KGTHRUSTINCLINEMOTOR) SPEED RANGE 0.5-15*MPH/0.8-24.1*KPH CONTACT & TELEMETRIC HR SENSORS DRIVE SYSTEM MOTOR MATRIX 5.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MOTOR CONTROLLER COMMERCIAL TREADMILL AC DRIVE console DISPLAY TYPE DOT-MATRIX LED TIME,TIMEELAPSED,TIMEREMAINING,TOTALPROGRAMTIME,CLOCK,DISTANCE(KI- DISPLAYFEEDBACK LOMETERS OR MILES), CALORIES, CALORIES PER HOUR, SPEED, INCLINE, PACE, HEART...

  • Page 55: Fasteners And Assembly Tools

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.2 faSTeNerS aNd aSSembly ToolS Part #: Part Name: Outline: Dimensions: Quantity: Bag Color: 020090-00 Socket head cap screw M8 x 20mm Black 0000086571 Flat Washer 6.2 x 12 x 1.6 Black 0000084935 Left Connection Bracket SPHC 4.0T 0000084936...

  • Page 56: Assembly Instructions

    Prior to assembling the treadmill, unpack all of the contents of the box and make sure that all necessary components are present. Review the contents of the hardware package for completeness. Contact Matrix customer service at 866.693.4863 to report any missing items.
  • Page 57 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.3 aSSembly iNSTrUCTioNS - CoNTiNUed STeP 4 STeP 3 Open Blue Assembly Bag. Slide the urethane arms over the steel Open White Assembly Bag. Assemble the left and right bracket tubes on the console base. Fasten the urethane arms to the steel (items 20 and 21) to the console base using item 12 socket head tubes using item 17 socket head cap screw and item 19 spacer.
  • Page 58 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.3 aSSembly iNSTrUCTioNS - CoNTiNUed STeP 5 STeP 6 Open Yellow Assembly Bag. Make appropriate wire connections to the faceplate and then assemble to the console base using item 13 socket head cap screw, item 23 lock washers, and item 16 socket head cap screw.
  • Page 59 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.3 aSSembly iNSTrUCTioNS - CoNTiNUed STeP 7 aSSembly ComPleTe Assembly is complete, the running belt should be adjusted as needed and the auto calibration sequence must now be run as outlined in Sections 3.4 and 3.5 Also level the unit as outlined in Section 10.4.

  • Page 60: Leveling The Unit

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.4 leVeliNG THe Treadmill oPTioNal leVeliNG aSSembly TeCHNiqUeS: USe of SHim or by addiNG a leVeliNG fooT. Note: It is extremely important that the levelers are correctly adjusted for proper operation. An unbalanced unit may cause belt misalignment or other issues.

  • Page 61: Mye Tv Bracket Installation Instructions

    10.5 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS The Matrix Treadmill is capable of having a MYE Entertainment or Web Ready (PCTV) television installed using an integrated bracket. Follow the instructions below to install the MYE TV and TV bracket and Section 10.6 for installation of a PCTV with a bracket, then use the instructions located in the TV owner's manual to program the TV.
  • Page 62 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 6) Stick the keypad to the cutout in the console plastic and press down to completely adhere the keypad to the plastic (Figure G). 7) Peel the protective film from the back of the entertainment overlay (Figure H). fiGUre G fiGUre H 8) Stick the overlay to the cutout in the console plastic and press down to completely adhere the overlay to the plastic and keypad (Figure I).
  • Page 63 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.5 mye TV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 12) Attach the coax cable from the TV bracket kit to the coax cable coming up the console mast (Figure M). note: There is an adaptor to hook the 2 male coax cable ends together included with the TV bracket kit.
  • Page 64 20) Install the console back cover using the 4 screws removed in Step 1 (Figure V). note: Make sure to route the wiring through the holes in the back cover so that none of the wiring is pinched (Figure W). The MATRIX logo portion of the back cover will not be used with a TV bracket.

  • Page 65: Pctv Tv Bracket Installation Instructions

    CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.6 PCTV TV braCkeT iNSTallaTioN iNSTrUCTioNS note: Section 10.6 is for installation of a TV bracket with a PCTV (web ready). See Section 10.5 if installing a MYE TV. 1) Remove the 4 screws holding the console back cover to the front and remove the console back cover (Figures A & B). fiGUre a fiGUre b 2) Slide the TV bracket between the console frame and the fan frame (Figure C).
  • Page 66 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.6 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 6) Plug the controller wire (this will have a white RJ45 connector on one end) into the bottom left hand corner of the UCB (Figure G). note: There is a wire in this location that will need to be removed to plug in the controller wire.
  • Page 67 15) Install the console back cover using the 4 screws removed in Step 1 (Figure Q). note: Make sure to route the wiring through the holes in the back cover so that none of the wiring is pinched (Figure R). The MATRIX logo portion of the back cover will not be used with a TV bracket.
  • Page 68 CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide 10.6 PCTV braCkeT iNSTallaTioN iNSTrUCTioNS - CoNTiNUed 16) Install the TV back cover using 4 screws (Figure S). 17) Plug the PCTV power wire into the port on the front of the treadmill near the power switch (Figure T). fiGUre S fiGUre T 18) Plug a coax cable with a signal strength of 10 Hz into the front of the treadmill near the power cord (Figure U).
  • Page 69 1. Create an access on USB folders which will be used. The access should be MATRIX\FW\UCB (create a folder called MATRIX, then a folder in MATRIX called FW, then a folder in FW called UCB). Or you can put USB in console and press ENTER, 9, 0, 0, 1, ENTER on the keypad and the USB will get the access.
  • Page 70 NoTeS...
  • Page 71 S S S y STe mS C or P. 1610 LANDM AR K D R IV E  C OTTAGE  G R O VE  WI  5 35 27 U S A TOLL FREE 866.693.486 3 w w w.matri x fi tne ss . c om FA X 60 8. 839 .1 71 7...
