Battery Run Time

RUN TIME CHART in Minutes
Output load
(1.4 kW)
UPS Model
PTX 2 M
+ 1 EB (40pcs)
+ 2 EB (80pcs)
+ 3 EB (120pcs)
PTX 2 M
+ 1 EB (40pcs)
+ 2 EB (80pcs)
+ 3 EB (120pcs)
EB: External Battery Bank
For 6kVA, using 7Ah/12VDC battery
For 10kVA, using 9Ah/12VDC battery
Indicates time not calculated, contact sales representative for details.
POWERTRONIX .
2 kVA 3 kVA 4 kVA
(2.1 kW) (2.8 kW)
38 22
158 95
297 180
446 273
54 31
216 131
402 246
602 370
- Page 28 of Total 29 -
5 kVA 6 kVA
(3.5 kW) (4.2 kW)
15 10 8
66 49 38
126 95 75
192 145 116
21 15 12
91 68 54
172 131 104
261 198 158
7 kVA 8 kVA 9 kVA
(4.9 kW) (5.6 kW) (6.3 kW)
9 7
44 37
85 72
131 110
January 2006
10 kVA
(7 kW)
6 5
31 27
62 54
95 83
