User manual 6/10 kVA Rev.2
3. Operation

Bypass Voltage

Step 1. To protect the load, the function of bypass auto-transfer is activated only when the AC
main voltage is within the range of LO (low) and HI(high). In this screen, press the "Enter" key
to confirm the following steps for LO/HI voltage setting.
Display 10 – Bypass Voltage Setting
Step 2. The cursor ( ) will pop up to indicate the item newly selected. Press the "Enter" key to
get the item of LO or HI range the user want to adjust.
Display 10 – Bypass Voltage Setting
Display 10 – Bypass Voltage Setting
Step 3. Use the "Select-Up" or "Select-Down" keys to adjust the voltage (changing 1V by every
press). LO (low range):176V+/- 20V, HI(high range):253V+/- 20V.
Step 4. Once the value is confirmed, press the "Enter" key again to save the data.
Display 10 – Bypass Voltage Setting
POWERTRONIX .
Bypass Volt Set
LO= 176V HI=253V
Bypass Volt Set
LO= 176V HI=253V
Bypass Volt Set
LO= 176V HI=253V
Bypass Volt Set
Save? NO
- Page 19 of Total 29 - January 2006
