User manual 6/10 kVA Rev.2

3. Operation

3.1 LCD and LED Display

LCD

"Select-Down" Key:
The welcome screen only shows for 10 seconds as UPS starts up,
after that the "UPS Status" will show on the display.
The screen should go back to "UPS Status" if you do not push any
buttons for 2 minutes.
Display 1 - Welcome screen
Display 2 - Input/Output Voltage
and Frequency
Identification
Display 3 – UPS Status
Display 4 – Real Input/Output
Voltage and Frequency
POWERTRONIX .
"Select-Up" Key:
POWERTRONIX UPS
On-Line UPS
Input:220V 50Hz
Output:220V 50Hz
AC:FAIL BATT:LOW
NO Output
Input Voltage
220 VAC
Output Voltage
220VAC
Input Frequency
50 Hz
Output Frequency
50 Hz
- Page 13 of Total 29 - January 2006
