3. Operation
Display 5 – Battery Voltage/
Capacity
Display 6 – Output Power
Display 7 – Inside Temperature
Display 8 – New Alarm
Display 9 – Old Alarm
Display 10 – Bypass Voltage Setting
Display 11 – Output Voltage/
Frequency Setting
POWERTRONIX .
Battery Voltage
240 VDC
Output Power
100 %
Inside TEMP
33 ℃ 91 ℉
NEW AC Fail: 1
ALM Overload: 3
OLD AC Fail:
ALM Overload: 9
Bypass Volt Set
LO= 176V HI=253V
Volt/Freq Set
220 VAC 50 Hz
