Summary of Contents for Matrix U7xi

  • Page 1 U7xi R7xi H7xi U7xe R7xe H7xe CYCLES OWNER’S MANUAL...
  • Page 2 IMPORTANT PRECAUTIONS HYBRID ASSEMBLY UPRIGHT ASSEMBLY RECUMBENT ASSEMBLY LOCATION & SETUP TROUBLESHOOTING & MAINTENANCE CYCLE OPERATION CYCLE WORKOUTS PRODUCT SPECIFICATIONS...
  • Page 3 SAVE THESE INSTRUCTIONS When using an Matrix Cycles, basic precautions should always be followed, including the following: Read all instructions before using this product. It is the responsibility of the owner to ensure that all users of this product are adequately informed of all warnings and precautions.
  • Page 4 DANGER TO REDUCE THE RISK OF ELECTRICAL SHOCK: Always unplug the unit from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or taking off parts. WARNING TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS: •...
  • Page 5 WARNING • Do not jump on the unit. • At no time should more than one person be on unit while in operation. • This unit should not be used by persons weighing more than specified in the OWNER’S MANUAL SPECIFICATIONS SECTION.
  • Page 6: Electrical Requirements

    CAUTION CONSULT A PHYSICIAN BEFORE USING THIS EQUIPMENT. READ OWNER’S MANUAL BEFORE USE. It is essential that your unit is used only indoors, in a climate controlled room. If your unit has been exposed to colder temperatures or high moisture climates, it is strongly recommended that the unit is warmed up to room temperature before first time use.
  • Page 7: Grounding Instructions

    110 V UNITS GROUNDING INSTRUCTIONS All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of The unit must be grounded. If it should malfunction or a 100-125 V, 60 Hz and a 15 A “Dedicated Circuit”, with a breakdown, grounding provides a path of least resistance non-looped (isolated) neutral/ground for power.
  • Page 8 ADD-ON PCTV (3X AND 5X) A 15 A or 20 A “Dedicated Circuit” with a non-looped (isolated) neutral/ground is required. Each PCTV requires at least 1.2 A of current. No more than 12 PCTVs should be used for each 15 A circuit and no more than 16 PCTVs should be used for each 20 A circuit.
  • Page 9 ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 10 INCLUDED FASTENERS FASTENERS REFERENCE SKETCH DESCRIPTION QUANTITY PACKAGE COLOR BUTTON HEAD BOLT(M8x25L) WHITE SPRING WASHER WHITE BUTTON HEAD BOLT(M5x10L) WHITE BUTTON HEAD BOLT(M8x20L) BLACK FLAT WASHER BLACK SPRING WASHER BLACK BUTTON HEAD BOLT(M8x15L) YELLOW FLAT WASHER YELLOW SPRING WASHER YELLOW BUTTON HEAD BOLT(M8x25L) BLUE BUTTON HEAD BOLT(M8x50L)
  • Page 11 Review the contents of the hardware PURPLE PHILLIPS DRIVER(6x130mm) package for completeness. Contact Matrix Customer Service at 1(866) 693-4863 to report any missing items. PURPLE OPEN WRENCH(#15#17 325L) Please make sure that the power plug is not plugged into PURPLE the wall outlet while completing the following procedure.
  • Page 12: Assembly Step

    ASSEMBLY STEP 1 BLACK HARDWARE BAG CONTENTS : BUTTON HEAD BOLT(M8x20L) FLAT WASHER SPRING WASHER Open BLACK HARDWARE BAG. Attach the STABILIZER TUBE to the MAIN FRAME using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side.
  • Page 13 ASSEMBLY STEP 2 YELLOW HARDWARE BAG CONTENTS BUTTON HEAD BOLT(M8x15L) FLAT WASHER SPRING WASHER Open YELLOW HARDWARE BAG. Attach MANUAL INCLINE LIFT LEVER to GUIDE RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (F) and 4 NUTS (G).
  • Page 14 ASSEMBLY STEP 3 RED HARDWARE BAG : GREEN HARDWARE BAG : Open RED AND GREEN HARDWARE BAGS. BUTTON HEAD BOLT(M8x50L) BUTTON HEAD BOLT(M8x15L) Attach the GUIDE RAIL SET to the ARC WASHER FLAT WASHER MAIN FRAME using 4 BOLTS (F), 4 SPRING WASHER SPRING WASHER SPRING WASHERS (E) and 4 FLAT...
  • Page 15 ASSEMBLY STEP 4 WHITE HARDWARE BAG CONTENTS : BUTTON HEAD BOLT(M8x25L) SPRING WASHER BUTTON HEAD BOLT(M5x10L) Open WHITE HARDWARE BAG. Carefully pull the CONSOLE CABLE through the CONSOLE MAST using the twist tie located inside the CONSOLE MAST. Attach CONSOLE MAST to MAIN FRAME using PRE-INSTALLED BOLTS AND WASHERS.
  • Page 16 ASSEMBLY STEP 5 7XI / 7XE / 5X CONSOLE ASSEMBLY Slide 1 FLAT WASHER (N), 1 7XE SHOWN WAVY WASHER (O) and another FLAT WASHER (N) onto the CONSOLE SCREW LOWER LINK ARM. Slide the LOWER LINK ARM into the PEDAL ARM BRACKET. Attach the LOWER LINK ARM to the PEDAL ARM BRACKET using 1 FLAT WASHER (R), 1...
  • Page 17 ASSEMBLY STEP 6 BLUE HARDWARE BAG CONTENTS : 7XE SHOWN BUTTON HEAD BOLT(M8x25L) Open HARDWARE BAG. Slide 1 RUBBER WASHER (S) and 1 FLAT WASHER (T) onto the CONSOLE MAST. Slide LOWER HANDLEBAR onto CONSOLE MAST and attach using 1 FLAT WASHER (T), 1 FLAT WASHER (H), 1 HANDLEBAR CAP, 1 FLAT WASHER (H), 1 SPRING WASHER (B) and 1 BOLT (U).
  • Page 19 ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 20 INCLUDED FASTENERS FASTENERS PACKAGE REFERENCE SKETCH DESCRIPTION AMOUNT COLOR BUTTON HEAD HEX SOCKET CAP SCREW(M8x25L) WHITE SPRING WASHER WHITE BUTTON HEAD SCREW(M5x10L) WHITE HEX SOCKET HEAD CAP SCREW(M8x20L) BLACK FLAT WASHER BLACK SPRING WASHER BLACK YELLOW BUTTON HEAD HEX SOCKET CAP SCREW W/NYLOC(M8x20L) SPRING WASHER YELLOW FLAT WASHER...
  • Page 21: Mm Allen Wrench

    PHILLIPS DRIVER(6x130mm) are present. Review the contents of the hardware package for completeness. Contact Matrix Customer Service at 1(866) 693-4863 to 5mm ALLEN WRENCH report any missing items. 3mm ALLEN WRENCH Please make sure that the power plug is not plugged into the wall outlet while completing the following procedure.
  • Page 22 ASSEMBLY STEP 1 BLACK HARDWARE BAG CONTENTS : HEX SOCKET HEAD CAP SCREW(M8x20L) FLAT WASHER SPRING WASHER Open BLACK HARDWARE BAG. Attach the STABILIZER TUBE to the MAIN FRAME using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side.
  • Page 23: Assembly Step

    ASSEMBLY STEP 2 RED HARDWARE BAG CONTENTS BUTTON HEAD HEX SOCKET CAP SCREW-CHROME PLATED(M8x20L) FLAT WASHER-CHROME PLATED SPRING WASHER-CHROME PLATED Open RED HARDWARE BAG. Attach MANUAL INCLINE LIFT LEVER to GUIDE RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (F) and 4 NUTS (G).
  • Page 24: Button Head Hex Socket Cap Screw W/Nyloc(M8X20L)

    ASSEMBLY STEP 3 YELLOW HARDWARE BAG CONTENTS : BUTTON HEAD HEX SOCKET CAP SCREW W/NYLOC(M8x20L) SPRING WASHER FLAT WASHER Open YELLOW HARDWARE BAG. Attach the STABILIZER TUBE to the MAIN FRAME using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side.
  • Page 25 ASSEMBLY STEP 4 WHITE HARDWARE BAG : GREEN HARDWARE BAG : BUTTON HEAD HEX SOCKET BUTTON HEAD HEX CAP SCREW (M8x25L) SOCKET CAP SCREW WITH NYLOC (M5x12L) SPRING WASHER BUTTON HEAD SCREW (M5x10L) Open WHITE AND GREEN HARDWARE BAGS. Attach MANUAL INCLINE LIFT LEVER to GUIDE RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (F) and 4 NUTS (G).
  • Page 26 ASSEMBLY STEP 5 7XI / 7XE / 5X CONSOLE ASSEMBLY 3X CONSOLE ASSEMBLY 7XE SHOWN CONSOLE SCREW CONSOLE SCREW...
  • Page 27 CONSOLE SCREW BLUE HARDWARE BAG CONTENTS : HEX SOCKET HEAD CAP SCREW(M8x25L) Open BLUE HARDWARE BAG. Attach the STABILIZER TUBE to the MAIN FRAME using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side. 7XE SHOWN ASSEMBLY COMPLETE!
  • Page 29 ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 30 INCLUDED FASTENERS REFERENCE SKETCH DESCRIPTION QUANTITY PACKAGE COLOR BUTTON HEAD BOLT(M8x25L) WHITE SPRING WASHER WHITE BUTTON HEAD BOLT(M5x10L) WHITE BUTTON HEAD BOLT(M8x20L) BLACK FLAT WASHER BLACK SPRING WASHER BLACK BUTTON HEAD BOLT(M8x15L) YELLOW FLAT WASHER YELLOW SPRING WASHER YELLOW BUTTON HEAD BOLT(M8x25L) BLUE BUTTON HEAD BOLT(M8x15L) BUTTON HEAD BOLT(M8x50L)
  • Page 31: Follow All Assembly Steps

    Review the contents of the hardware package for completeness. PHILLIPS DRIVER(6x130mm) Contact Matrix Customer Service at 1(866) 693-4863 to report any missing items. OPEN WRENCH(#15#17 325L) Please make sure that the power plug is not plugged into 5mm ALLEN WRENCH the wall outlet while completing the following procedure.
  • Page 32 ASSEMBLY STEP 1 BLACK HARDWARE BAG CONTENTS : BUTTON HEAD BOLT(M8x20L) FLAT WASHER SPRING WASHER Open BLACK HARDWARE BAG. Attach the STABILIZER TUBE to the MAIN FRAME using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side.
  • Page 33 ASSEMBLY STEP 2 YELLOW HARDWARE BAG CONTENTS BUTTON HEAD BOLT(M8x15L) FLAT WASHER SPRING WASHER Open YELLOW HARDWARE BAG. Attach MANUAL INCLINE LIFT LEVER to GUIDE RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (F) and 4 NUTS (G).
  • Page 34 ASSEMBLY STEP 3 Open RED HARDWARE BAG. RED HARDWARE BAG CONTENTS : Attach the STABILIZER TUBE to the MAIN FRAME BUTTON HEAD BOLT(M8x15L) using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 BUTTON HEAD BOLT(M8x50L) ARC WASHERS (C) on each side. ARC WASHER SPRING WASHER BUTTON HEAD BOLT(M8x15L)
  • Page 35 ASSEMBLY STEP 4 WHITE HARDWARE BAG : BLUE HARDWARE BAG : BUTTON HEAD BOLT BUTTON HEAD BOLT (M8x25L) (M8x25L) SPRING WASHER BUTTON HEAD BOLT (M5x10L) Open WHITE AND BLUE HARDWARE BAGS. Z13 Z34 Attach MANUAL INCLINE LIFT LEVER to GUIDE RAIL SET using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (F) and 4 NUTS (G).
  • Page 36 ASSEMBLY STEP 5 7XI / 7XE / 5X CONSOLE ASSEMBLY 3X CONSOLE ASSEMBLY 7XE SHOWN CONSOLE SCREW CONSOLE SCREW...
  • Page 37 Attach the CONSOLE to the CONSOLE MAST using 2 PRE-INSTALLED SCREWS. CONSOLE SCREW 7XE SHOWN ASSEMBLY COMPLETE!
  • Page 39 LOCATION & SETUP...
  • Page 40 LOCATION OF THE EXERCISE BIKE Place the unit on a level and stable surface away from direct sunlight. The intense UV light can cause discoloration on the plastics. Locate your unit in an area with cool temperatures and low humidity. Please leave a clear zone on both sides of 24”...
  • Page 41 TROUBLESHOOTING & MAINTENANCE...
  • Page 42: Recommended Cleaning Tips

    CAUTION: Be sure to have proper assistance to install and move the unit in order to avoid injury or damage. CHECK FOR DAMAGED PARTS DO NOT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness.
  • Page 43: Care And Maintenance

    DAILY • Unplug the unit. Clean entire machine using water and a mild soap or other Matrix approved solution (cleaning agents should be alcohol and ammonia free). WARNING • Inspect the power cord. If the power cord is damaged, contact Customer Tech Support.
  • Page 44 The site provides information including serial numbers, time/distance totals, software versions, and a history of any error codes that the unit has shown. The system will send email notifications for any error messages that occur on the equipment, notifying both Matrix Fitness customer support and the facility.
  • Page 45 CYCLE OPERATION...
  • Page 46 POWER Your exercise bike may be powered by a power supply. The power must be plugged into the power jack, which is located in the front of the machine near the stabilizer tube. Unplug cord when not in use. WARNING Never operate product if it has a damaged cord or plug, if it is not working properly, if it has been damaged, or immersed in water.
  • Page 47: Proper Usage

    PROPER USAGE To determine proper seat position, sit on the seat and position the ball of your foot on the center of the pedal. Your knee should bend slightly at the furthest pedal position. You should be able to pedal without locking your knees or shifting your weight from side to side.
  • Page 48 USING THE HEART RATE FUNCTION The unit is equipped with heart rate pulse grips. The heart rate function on this product is not a medical device. While heart rate grips can provide a relative estimation of your actual heart rate, they should not be relied on when accurate readings are necessary. Some people, including those in a cardiac rehab program, may benefit from using an alternate heart rate monitoring system like a chest or wrist strap.
  • Page 49: Wireless Heart Rate Receiver

    WIRELESS HEART RATE RECEIVER When used in conjunction with a wireless chest transmitter, your heart rate can be transmitted wirelessly to the unit and displayed on the console. Prior to wearing the wireless chest transmitter on your chest, moisten the two rubber electrodes with water. Center the chest strap just below the breast or pectoral muscles, directly over your sternum, with the logo facing out.
  • Page 51 H3X/ U3X / R3X CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us A) WORKOUT KEYS: Simple program view and selection buttons.
  • Page 53 H5X / U5X / R5X CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us A) WORKOUT KEYS: Simple program view and selection buttons.
  • Page 55 H7XE / U7XE / R7XE CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us The 7xe has a fully integrated touch screen display.
  • Page 57 H7XI / U7XI / R7XI CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
  • Page 58 7XI CONSOLE OPERATION GETTING STARTED (For help or more information, touch ?.) WELCOME SCREEN • Touch the USER button to sign-in with your XID. • Touch the GUEST button to workout anonymously. • Touch the REGISTER button to create a new XID. USER SIGN-IN 1) Enter your XID and touch 2) Enter your PASSCODE and touch...
  • Page 59 HOMESCREEN: FEATURED CONTENT • When the workout starts, featured content is displayed. Touch to access homescreen. HOMESCREEN • The USERNAME or GUEST is shown in the upper right-hand corner. • Touch to change WORKOUT STATISTICS displayed at the bottom of the screen. •...
  • Page 60 7XI APPS AND ENTERTAINMENT PROFILE / VIRTUAL ACTIVE SCREEN: • FEATURED CONTENT - Displays featured videos, music and • MEDIA PLAYER - Connect and control audio and workouts according to frequently-accessed content. video files on-screen via USB port. • ON DEMAND TV - Watch On Demand video content •...
  • Page 61 NIKE + IPOD INSTRUCTIONS (7XE CONSOLES ONLY) REQUIREMENTS Nike + iPod – compatible iPod or iPhone (See www.apple.com/nikeplus for more information). Before syncing your Apple device, you must first create a free Nike + iPod account at www.nikerunning.com and have the Nike + iPod App turned on in the settings of your device. GETTING STARTED 1) Before connecting your Apple device, you must first turn on Nike + iPod within the settings of the device.
  • Page 62 MANAGER MODE AND ENGINEERING MODE 3X AND 5X CONSOLES: These sections allow users to manipulate default settings for the machines. It may be accessed by pressing the Level Up / Level Down keys simultaneously for 5 seconds. To change a setting, press “Enter” on the keypad under ‘Manager Mode’ or ‘Engineering Mode’...
  • Page 63 7XE - MANAGER AND ENGINEERING MODE 7XI - MANAGER AND ENGINEERING MODE...
  • Page 65 CYCLE WORKOUTS NOTE: The individual human power required to perform an exercise may be different than the mechanical power displayed. These exercise devices are a Class A products. These products display the power input into the exercise device in watts. These products have been tested to ensure that the watts displayed on the console is accurate to within +/- 10 % when the power input is greater than 50W, and is accurate to within +/- 5 W when the power input is 50W or below.
  • Page 66 WORKOUT DESCRIPTIONS QUICK START OPERATION Press the GO button and the machine will enter into a manual mode of operation. All energy expenditure values will be calculated using the default weight measurement. MANUAL WORKOUT OPERATION Manual is a workout that allows you to manually adjust the resistance levels at any time. The manual workout also contains a setup screen which allows you to input your weight to help calculate a more accurate caloric burn rate.
  • Page 67 LEVEL BASED PROGRAMS Your Matrix machine offers a variety of level-based workouts to challenge users of all fitness levels. The following information will briefly explain the workout and how to program the machine for each workout selection. ROLLING HILLS WORKOUT OPERATION...
  • Page 68 WORKOUT DESCRIPTIONS USER DEFINED PROGRAMS (RANDOM) FAT BURN WORKOUT OPERATION There are 20 workout profiles in random mode. Profile will Fat burn is a level-based workout that is designed to help change each time random button is pressed. users burn fat through various resistance changes. To enter into this workout on the 3x or 5x, use the following To enter into this workout on the 3x or 5x, use the following guidelines.
  • Page 69 HEART RATE CONTROL WORKOUT OPERATION FITNESS TEST Your Matrix machine offers a heart rate control workout This test measures cardiovascular fitness and proves an mode. The heart rate control workout mode allows the estimated sub-maximal VO2 result. It is based on power output...
  • Page 70 WORKOUT DESCRIPTIONS CONSTANT WATTS This program allows you to vary your cadence or RPM and the machine’s resistance will adjust accordingly to your selected goal. The quicker your stride the less resistance for the goal selected. To enter into this workout on the 3x or 5x, use the following guidelines. To enter into this workout on the 7xe and 7xi, follow the on-screen prompts.
  • Page 71 PRODUCT SPECIFICATIONS...
  • Page 72: Product Specifications

    CONSOLE 16” / 40.6 CM CLASS PROJECTIVE CAPACITIVE 14-SEG ALPHANUMERIC, 8X16 LED GRAPHIC DISPLAY TYPE 15” / 38.1 CM TOUCH SCREEN LCD DOT-MATRIX LED TOUCH SCREEN LCD (16:9) DISPLAY TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL...
  • Page 73 CONSOLE 16” / 40.6 CM CLASS PROJECTIVE CAPACITIVE 14-SEG ALPHANUMERIC, 8X16 LED GRAPHIC DISPLAY TYPE 15” / 38.1 CM TOUCH SCREEN LCD DOT-MATRIX LED TOUCH SCREEN LCD (16:9) DISPLAY TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL...
  • Page 74 PRODUCT SPECIFICATIONS U7xi UPRIGHT U7xe UPRIGHT U5x UPRIGHT U3x UPRIGHT FEATURES CONTACT & TELEMETRIC HR SENSORS YES HANDLEBAR DESIGN FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT...
  • Page 76 Matrix Fitness 1-866-693-4863 1600 Landmark Drive, www.matrixfitness.com Cottage Grove, WI 53527 Matrix Bikes 1.7.1 | © 2013 Matrix Fitness...
