Matrix U7xi Owner's Manual

Cycle trainer
Hide thumbs Also See for U7xi:
Table of Contents

Advertisement

Quick Links

See also: User Manual
U7xi
R7xi
U7xe
R7xe
U5x
R5x
U3x
R3x
CYCLES OWNER'S MANUAL
H7xi
H7xe
H5x
H3x

Advertisement

Table of Contents
loading

Related Manuals for Matrix U7xi

Summary of Contents for Matrix U7xi

  • Page 1 U7xi R7xi H7xi U7xe R7xe H7xe CYCLES OWNER’S MANUAL...
  • Page 2 IMPORTANT PRECAUTIONS HYBRID ASSEMBLY UPRIGHT ASSEMBLY RECUMBENT ASSEMBLY LOCATION & SETUP TROUBLESHOOTING & MAINTENANCE CYCLE OPERATION CYCLE WORKOUTS PRODUCT SPECIFICATIONS...

  • Page 3: Important Precautions

    SAVE THESE INSTRUCTIONS When using Matrix Cycles, basic precautions should always be followed. Read all instructions before using this product. It is the responsibility of the owner to ensure that all users of this product are adequately informed of all warnings and precautions.
  • Page 4 DANGER TO REDUCE THE RISK OF ELECTRICAL SHOCK: Always unplug the unit from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or taking off parts. WARNING TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS: •...
  • Page 5 WARNING • Do not jump on the unit. • At no time should more than one person be on unit while in operation. • This unit should not be used by persons weighing more than specified in the OWNER’S MANUAL SPECIFICATIONS SECTION.

  • Page 6: Electrical Requirements

    CAUTION CONSULT A PHYSICIAN BEFORE USING THIS EQUIPMENT. READ OWNER’S MANUAL BEFORE USE. It is essential that your unit is used only indoors, in a climate controlled room. If your unit has been exposed to colder temperatures or high moisture climates, it is strongly recommended that the unit is warmed up to room temperature before first time use.

  • Page 7: Grounding Instructions

    110 V UNITS GROUNDING INSTRUCTIONS All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of The unit must be grounded. If it should malfunction or a 100-125 V, 60 Hz and a 15 A “Dedicated Circuit”, with a breakdown, grounding provides a path of least resistance non-looped (isolated) neutral/ground for power.
  • Page 8 ADD-ON PCTV (3X AND 5X) A 15 A or 20 A “Dedicated Circuit” with a non-looped (isolated) neutral/ground is required. Each PCTV requires at least 1.2 A of current. No more than 12 PCTVs should be used for each 15 A circuit and no more than 16 PCTVs should be used for each 20 A circuit.
  • Page 9 (example: Hybrid Cycle). ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 10 SEAT BACK PULSE GRIPS / RESISTANCE TOGGLES ARM REST HANDLEBARS CONSOLE SEAT FRAME PULSE GRIP HANDLEBARS SEAT BASE CONSOLE MAST SEAT RAMP CRANK MAIN FRAME PEDALS REAR FRAME HANDLE FRONT SHROUD COVER REAR FRAME COVER FRONT STABILIZER TUBE REAR STABILIZER TUBE TRANSPORT WHEELS SEAT ADJUSTMENT LEVER POWER CORD SOCKET...

  • Page 11: Before You Begin

    BEFORE YOU BEGIN TOOLS REQUIRED: Prior to assembling the unit, unpack all of the contents of F 4 mm Allen Wrench the box and make sure that all necessary components are F 6 mm Allen Wrench present. Review the contents of the hardware package for completeness.
  • Page 12 HYBRID ASSEMBLY STEP 1 YELLOW HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X25L FLAT WASHER Φ8.2XΦ16.0X2.0T Open YELLOW HARDWARE BAGS. Attach the FRONT STABILIZER TUBE (1) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B). Attach the REAR STABILIZER TUBE (3) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B).
  • Page 13 HYBRID ASSEMBLY STEP 2 BLACK HARDWARE BAG PART TYPE DESCRIPTION QTY SOCKET HEAD BOLT (BLACK) M8X20L PHIILIP HEAD BOLT M5X12L Open BLACK HARDWARE BAG. Attach the REAR FRAME HANDLE (3) to the MAIN FRAME (2) using 2 BOLTS (C). Attach the REAR FRAME COVER (4) to the MAIN FRAME (2) using 2 BOLTS (D).
  • Page 14 HYBRID ASSEMBLY STEP 3 GREEN HARDWARE BAG PART TYPE DESCRIPTION PHILLIP HEAD BOLT M5X12L Open GREEN HARDWARE BAG. Attach the FRONT SHROUD COVER (7) to the MAIN FRAME (2) using 4 BOLTS (G). BLUE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M10X25L HEAVY WASHER Φ10.0XΦ28.0X5.0T...
  • Page 15 HYBRID ASSEMBLY STEP 4 PURPLE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X50L SPRING WASHER Φ8.2XΦ13.5.0X2.0T WAVE WASHER Φ8.2XΦ18.0X1.5T Open PURPLE HARDWARE BAG. Attach the SEAT BASE (10) to the SEAT FRAME (9) using 4 BOLTS (J), 4 SPRING WASHERS (K) and 4 WAVE WASHERS (L).
  • Page 16 HYBRID ASSEMBLY STEP 5 WHITE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X20L Open WHITE HARDWARE BAG. Carefully pull the PULSE GRIP CABLES (12) through the CONSOLE MAST(6) using the twist tie located inside the CONSOLE MAST (6). Attach the PULSE GRIP HANDLEBARS (13) to the CONSOLE MAST (6) using 4 BOLTS (N).
  • Page 17 HYBRID ASSEMBLY COMPLETE!
  • Page 19 (example: Upright Cycle). ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 20 PULSE GRIPS RESISTANCE TOGGLES WATER BOTTLE POCKETS CONSOLE HANDLEBARS ACCESSORY TRAY SEAT CONSOLE MAST CRANK SEAT ADJUSTMENT LEVER PEDALS STEP PLATE REAR FRAME HANDLE FRONT SHROUD COVER REAR FRAME COVER FRONT STABILIZER TUBE REAR STABILIZER TUBE TRANSPORT WHEELS MAIN FRAME POWER CORD SOCKET...
  • Page 21 BEFORE YOU BEGIN TOOLS REQUIRED: Prior to assembling the unit, unpack all of the contents of F 4 mm Allen Wrench the box and make sure that all necessary components are F 6 mm Allen Wrench present. Review the contents of the hardware package for completeness.
  • Page 22 UPRIGHT ASSEMBLY STEP 1 YELLOW HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X25L FLAT WASHER Φ8.2XΦ16.0X2.0T Open YELLOW HARDWARE BAG. Attach the FRONT STABILIZER TUBE (1) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B). Attach the REAR STABILIZER TUBE (3) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B).
  • Page 23 UPRIGHT ASSEMBLY STEP 2 BLACK HARDWARE BAG PART TYPE DESCRIPTION QTY SOCKET HEAD BOLT (BLACK) M8X20L PHIILIP HEAD BOLT M5X12L Open BLACK HARDWARE BAG. Attach the REAR FRAME HANDLE (3) to the MAIN FRAME (2) using 2 BOLTS (C). Attach the REAR FRAME COVER (4) to the MAIN FRAME (2) using 2 BOLTS (D).
  • Page 24 UPRIGHT ASSEMBLY STEP 3 GREEN HARDWARE BAG PART TYPE DESCRIPTION PHILLIP HEAD BOLT M5X12L Open GREEN HARDWARE BAG. Attach the FRONT SHROUD COVER (7) to the MAIN FRAME (2) using 2 BOLTS (G). Attach the STEP PLATE (8) to the MAIN FRAME (2) using 2 BOLTS (G).
  • Page 25 UPRIGHT ASSEMBLY STEP 4 WHITE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X20L A Open WHITE HARDWARE BAG. B Carefully pull the PULSE GRIP CABLES (9) through the CONSOLE MAST (6) using the twist tie located inside the CONSOLE MAST (6). C Attach the PULSE GRIPS HANDLEBARS (10) to the CONSOLE MAST (6) using 4 BOLTS (H).
  • Page 26 UPRIGHT ASSEMBLY STEP 5 PURPLE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X20L SPRING WASHER Φ8.2XΦ13.5X2.0T Open PURPLE HARDWARE BAG. Attach the SEAT (13) to the SEAT POST (14) using 4 BOLTS (C) and 4 SPRING WASHERS (I). Attach the CONSOLE CABLES (5) to the CONSOLE (15).
  • Page 27 UPRIGHT ASSEMBLY COMPLETE!
  • Page 29 (example: Recumbent Cycle). ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW: CONSOLE SERIAL NUMBER LOCATION FRAME SERIAL NUMBER: CONSOLE SERIAL NUMBER: MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service.
  • Page 30 SEAT BACK CONSOLE SEAT BASE CONSOLE HANDLEBARS SEAT FRAME CONSOLE MAST SEAT RAMP PULSE GRIPS / RESISTANCE TOGGLES WATER BOTTLE POCKETS CRANK SEAT ADJUSTMENT LEVER PEDALS REAR FRAME HANDLE FRONT SHROUD COVER REAR STABILIZER TUBE FRONT STABILIZER TUBE REAR FRAME COVER TRANSPORT WHEELS MAIN FRAME POWER CORD SOCKET...
  • Page 31 BEFORE YOU BEGIN TOOLS REQUIRED: Prior to assembling the unit, unpack all of the contents of F 4 mm Allen Wrench the box and make sure that all necessary components are F 6 mm Allen Wrench present. Review the contents of the hardware package for completeness.
  • Page 32 RECUMBENT ASSEMBLY STEP 1 YELLOW HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X25L FLAT WASHER Φ8.2XΦ16.0X2.0T Open YELLOW HARDWARE BAG. Attach the FRONT STABILIZER TUBE (1) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B). Attach the REAR STABILIZER TUBE (3) to the MAIN FRAME (2) using 4 BOLTS (A) and 4 FLAT WASHERS (B).
  • Page 33 RECUMBENT ASSEMBLY STEP 2 BLACK HARDWARE BAG PART TYPE DESCRIPTION QTY SOCKET HEAD BOLT (BLACK) M8X20L PHIILIP HEAD BOLT M5X12L Open BLACK HARDWARE BAG. Attach the REAR FRAME HANDLE (3) to the MAIN FRAME (2) using 2 BOLTS (C). Attach the REAR FRAME COVER (4) to the MAIN FRAME (2) using 2 BOLTS (D).
  • Page 34 RECUMBENT ASSEMBLY STEP 3 WHITE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X20L Open WHITE HARDWARE BAG. Attach the CONSOLE HANDLEBARS (7) to the CONSOLE MAST (6) using 4 BOLTS (G). GREEN HARDWARE BAG PART TYPE DESCRIPTION PHILLIPS HEAD BOLT M5X12L Open GREEN HARDWARE BAG.
  • Page 35 RECUMBENT ASSEMBLY STEP 4 PINK HARDWARE BAG PART TYPE DESCRIPTION PHILLIPS HEAD BOLT M5X12L Open PINK HARDWARE BAG. Attach the WATER BOTTLE HOLDERS (9) to the SEAT FRAME (10) using 4 BOLTS (D). BLUE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X15L SPRING WASHER Φ8.2XΦ15.4X2.0T...
  • Page 36 RECUMBENT ASSEMBLY STEP 5 PURPLE HARDWARE BAG PART TYPE DESCRIPTION SOCKET HEAD BOLT M8X50L SPRING WASHER Φ8.2XΦ13.5.0X2.0T WAVE WASHER Φ8.2XΦ18.0X1.5T Open PURPLE HARDWARE BAG. Attach the SEAT BASE (11) to the SEAT FRAME (10) using 4 BOLTS (J), 4 SPRING WASHERS (K) and 4 WAVE WASHERS (L).
  • Page 37 RECUMBENT ASSEMBLY STEP 6 NOTE: All hardware for this step is pre- installed. Attach the CONSOLE CABLES (5) to the CONSOLE (13). Attach the CONSOLE (13) to the CONSOLE MAST (6) using 5 PRE-INSTALLED BOLTS (14). Attach PEDALS (15) to the CRANK (16) with the provided 15mm/17mm flat wrench.
  • Page 38 RECUMBENT ASSEMBLY COMPLETE!

  • Page 39: Location & Setup

    LOCATION & SETUP...
  • Page 40 LOCATION OF THE EXERCISE BIKE Place the unit on a level and stable surface away from direct sunlight. The intense UV light can cause discoloration on the plastics. Locate your unit in an area with cool temperatures and low humidity. Please leave a clear zone 24”...

  • Page 41: Troubleshooting And Maintenance

    TROUBLESHOOTING & MAINTENANCE...

  • Page 42: Recommended Cleaning Tips

    RECOMMENDED CLEANING TIPS Preventative maintenance and daily cleaning will prolong the life and look of your equipment. A Use a soft, clean cotton cloth. DO NOT use paper towels to clean surfaces on the bike. Paper towels are abrasive and can damage surfaces.

  • Page 43: Care And Maintenance

    DAILY • Unplug the unit. Clean entire machine using water and a mild soap or other Matrix approved solution (cleaning agents should be alcohol and ammonia free). WARNING • Inspect the power cord. If the power cord is damaged, contact Customer Tech Support.
  • Page 44 The site provides information including serial numbers, time/distance totals, software versions, and a history of any error codes that the unit has shown. The system will send email notifications for any error messages that occur on the equipment, notifying both Matrix Fitness customer support and the facility.

  • Page 45: Cycle Operation

    CYCLE OPERATION...

  • Page 46: Hybrid Seat Height

    POWER Your exercise bike may be powered by a power supply. The power must be plugged into the power port, which is located in the front of the machine near the stabilizer tube. Unplug cord when not in use. WARNING Never operate product if it has a damaged cord or plug, if it is not working properly, if it has been damaged, or immersed in water.

  • Page 47: Proper Usage

    PROPER USAGE To determine proper seat position, sit on the seat and position the ball of your foot on the center of the pedal. Your knee should bend slightly at the furthest pedal position. You should be able to pedal without locking your knees or shifting your weight from side to side.
  • Page 48 USING THE HEART RATE FUNCTION The unit is equipped with heart rate pulse grips. The heart rate function on this product is not a medical device. While heart rate grips can provide a relative estimation of your actual heart rate, they should not be relied on when accurate readings are necessary. Some people, including those in a cardiac rehab program, may benefit from using an alternate heart rate monitoring system like a chest or wrist strap.

  • Page 49: Wireless Heart Rate Receiver

    WIRELESS HEART RATE RECEIVER When used in conjunction with a wireless chest transmitter, your heart rate can be transmitted wirelessly to the unit and displayed on the console. Prior to wearing the wireless chest transmitter on your chest, moisten the two rubber electrodes with water. Center the chest strap just below the breast or pectoral muscles, directly over your sternum, with the logo facing out.
  • Page 51 H3X/ U3X / R3X CONSOLE DESCRIPTION This equipment is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us WORKOUT KEYS: Simple program view and selection buttons.
  • Page 53 H5X / U5X / R5X CONSOLE DESCRIPTION This equipment is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us WORKOUT KEYS: Simple program view and selection buttons.
  • Page 55 H7XE / U7XE / R7XE CONSOLE DESCRIPTION This equipment is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before us The 7xe has a fully integrated touch screen display.
  • Page 57 H7XI / U7XI / R7XI CONSOLE DESCRIPTION This equipment is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.

  • Page 58: Welcome Screen

    7XI CONSOLE OPERATION GETTING STARTED (For help or more information, touch ?.) WELCOME SCREEN • Touch the USER button to sign-in with your XID. • Touch the GUEST button to workout anonymously. • Touch the REGISTER button to create a new XID. USER SIGN-IN 1) Enter your XID and touch 2) Enter your PASSCODE and touch...

  • Page 59: Home Screen

    HOMESCREEN: FEATURED CONTENT • When the workout starts, featured content is displayed. Touch to access homescreen. HOMESCREEN • The USERNAME or GUEST is shown in the upper right-hand corner. • Touch to change WORKOUT STATISTICS displayed at the bottom of the screen. •...
  • Page 60 7XI APPS AND ENTERTAINMENT PROFILE / VIRTUAL ACTIVE SCREEN: • FEATURED CONTENT - Displays featured videos, music and • MEDIA PLAYER - Connect and control audio and workouts according to frequently-accessed content. video files on-screen via USB port. • ON DEMAND TV - Watch On Demand video content •...

  • Page 61: Getting Started

    NIKE + IPOD INSTRUCTIONS (7XE CONSOLES ONLY) REQUIREMENTS Nike + iPod – compatible iPod or iPhone (See www.apple.com/nikeplus for more information). Before syncing your Apple device, you must first create a free Nike + iPod account at www.nikerunning.com and have the Nike + iPod App turned on in the settings of your device. GETTING STARTED 1) Before connecting your Apple device, you must first turn on Nike + iPod within the settings of the device.
  • Page 62 MANAGER MODE AND ENGINEERING MODE 3X AND 5X CONSOLES: These sections allow users to manipulate default settings for the machines. It may be accessed by pressing the Level Up / Level Down keys simultaneously for 5 seconds. To change a setting, press “Enter” on the keypad under ‘Manager Mode’ or ‘Engineering Mode’...
  • Page 63 7XE - MANAGER AND ENGINEERING MODE 7XI - MANAGER AND ENGINEERING MODE...
  • Page 65 CYCLE WORKOUTS NOTE: The individual human power required to perform an exercise may be different than the mechanical power displayed. These exercise devices are a Class A products. These products display the power input into the exercise device in watts. These products have been tested to ensure that the watts displayed on the console is accurate to within +/- 10 % when the power input is greater than 50W, and is accurate to within +/- 5 W when the power input is 50W or below.

  • Page 66: Workout Descriptions

    WORKOUT DESCRIPTIONS QUICK START OPERATION Press the GO button and the machine will enter into a manual mode of operation. All energy expenditure values will be calculated using the default weight measurement. MANUAL WORKOUT OPERATION Manual is a workout that allows you to manually adjust the resistance levels at any time. The manual workout also contains a setup screen which allows you to input your weight to help calculate a more accurate caloric burn rate.

  • Page 67: Interval Training

    LEVEL BASED PROGRAMS Your Matrix machine offers a variety of level-based workouts to challenge users of all fitness levels. The following information will briefly explain the workout and how to program the machine for each workout selection. ROLLING HILLS WORKOUT OPERATION...
  • Page 68 WORKOUT DESCRIPTIONS USER DEFINED PROGRAMS (RANDOM) FAT BURN WORKOUT OPERATION There are 20 workout profiles in random mode. Profile will Fat burn is a level-based workout that is designed to help change each time random button is pressed. users burn fat through various resistance changes. To enter into this workout on the 3x or 5x, use the following To enter into this workout on the 3x or 5x, use the following guidelines.

  • Page 69: Heart Rate Control Workout Operation

    HEART RATE CONTROL WORKOUT OPERATION FITNESS TEST Your Matrix machine offers a heart rate control workout This test measures cardiovascular fitness and provides an mode. The heart rate control workout mode allows the estimated sub-maximal VO2 result. It is based on power output...

  • Page 70: Constant Watts

    WORKOUT DESCRIPTIONS CONSTANT WATTS This program allows you to vary your cadence or RPM and the machine’s resistance will adjust accordingly to your selected goal. The quicker your stride the less resistance for the goal selected. To enter into this workout on the 3x or 5x, use the following guidelines. To enter into this workout on the 7xe and 7xi, follow the on-screen prompts.

  • Page 71: Product Specifications

    PRODUCT SPECIFICATIONS...
  • Page 72 16” / 40.6 CM CLASS PROJECTIVE CAPACITIVE 14-SEG ALPHANUMERIC, 8X16 LED GRAPHIC, DISPLAY TYPE 15” / 38.1 CM TOUCH SCREEN LCD DOT MATRIX LED WITH PROFILE DISPLAY TOUCH SCREEN LCD (16:9) DOT MATRIX LED WITH PROFILE DISPLAY TIME ELAPSED, TIME REMAINING, TOTAL...
  • Page 73 CONSOLE 16” / 40.6 CM CLASS PROJECTIVE CAPACITIVE 14-SEG ALPHANUMERIC, 8X16 LED GRAPHIC DISPLAY TYPE 15” / 38.1 CM TOUCH SCREEN LCD DOT-MATRIX LED TOUCH SCREEN LCD (16:9) DISPLAY TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL TIME ELAPSED, TIME REMAINING, TOTAL...
  • Page 74 UPRIGHT CYCLE PRODUCT SPECIFICATIONS CONSOLE U7xi U7xe FRAME H-3x-5x-7x FEATURES CONTACT & TELEMETRIC HR SENSORS YES HANDLEBAR DESIGN FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT FULL RACING STYLE WITH ELBOW SUPPORT...
  • Page 76 Matrix Bikes 1.9.2 (-04) | © 2013 Matrix Fitness...
