P90L 6kVA & 10kVA User's Manual
There are 4 buttons on front panel.
Button
ON/ENTER
OFF/ESC
UP*
DOWN*
*If pressing UP and DOWN button together, the LCD display will rotate 90° automatically. This operation is used
when configuring the UPS to Rack or Tower display.

LED Indicators

There are 4 LEDs on front panel to show the UPS working status:
Mode
UPS power on
Bypass mode
Line mode / Converter mode
Battery mode
Fault mode
Battery test mode
ECO mode
Note: ● means LED is lit; ○ means LED is off; ● means LED is flashing.

Audible Alarm

UPS status
Bypass mode
Battery / Battery-test mode (normal battery voltage)
Battery / Battery-test mode (low battery voltage)
Fault
Warnings (except overload)
Overload
Other

UPS Operation

Turn on the UPS with utility power supply (to Line mode)
1. Make sure mains input and battery are connected , and the battery pack breaker is in the
"ON" position; Set the external mains input breaker to "ON" position, then the fan will be run-
Xtreme Power Conversion Corporation
Function
• Press this button to turn on the UPS.
• Or press it to confirm the selection in the menu.
• Press this button to turn off the UPS.
• Or press it to return to last menu.
• Press this button to select the previous item in the menu.
• Or press this button to jump to previous page in the screen.
• Or press this button to increase the number in the setting.
• Press this button to select the next item in the menu.
• Or press this button to jump to next page in the screen.
• Or press this button to decrease the number in the setting.
Bypass
●
●
○
○
○
○
●
Line Battery
●
○
●
○
○
●
●
Buzzer status
Beeping once every 2 minutes
Beeping once every 4 seconds
Beeping once every second
Beeping continuously
Beeping once every second
Beeping twice every second
Mute
Uninterruptible Power Supply
Fault
● ●
○ ○
○ ○
● ○
○ ●
● ○
○ ○
