STEP 2 – Set Up the CapTel
For Desktop Use
1. Plug the AC adapter cord into the
round power jack on the bottom
of the CapTel.
2. Plug the telephone line cord into
the first (left) telephone line jack.
3. Attach the desktop/wall footplate,
making sure the larger side is
along the top edge of the CapTel.
4. Plug the telephone line cord into
the wall jack and the AC adapter
into an electrical outlet.
For Mounting on Wall
To mount the CapTel on a wall, follow the above instructions
with the following changes:
1. Flip the handset hook over so
that the hook points up.
2. Plug the 6-inch telephone line cord
into the telephone jack.
3. Attach the desktop/wall footplate,
making sure the larger side is down.
4. Plug the telephone cord into
the wall jack. Then, line up
the holes in the desktop/wall
footplate with the studs on the wall.
Hook the footplate on the studs and pull down.
NOTE: To personalize the menu settings after setup, see
pages 18-23. For additional setup instructions, see page 36.
