USER MANUAL
Safety Information............................................................. 3
Specifications.................................................................... 4
Main Power Connection..................................................... 5
DMX-512 Connection......................................................... 5
DMX Profile.................................................................................... 7
Main Control Menu......................................................................... 8
Rigging the Fixture.............................................................10
Cleaning & Maintenance................................................................10
Parts List........................................................................................ 10
Advertisement
Table of Contents
Related Manuals for Mega Lite Drama LED Q170
Summary of Contents for Mega Lite Drama LED Q170
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………. 3 Specifications………………………………………………………….. 4 Main Power Connection…………………………………………….. 5 DMX-512 Connection……………………………...……………..5 DMX Profile..................7 Main Control Menu................. 8 Rigging the Fixture…………………………………………………….10 Cleaning & Maintenance..............10 Parts List..................10... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Technical Information
Technical Information Part Numbers Fixture 7010-Drama LED Q170 Mechanical Specifications DMX Connectors: 3-pin XLR connectors in/out 22.25” Power Connections: Neutrik Power Con to Male Nema 5 15 Thermal: Maximum ambient temperature 104°F Maximum surface temperature 130° C Display: Digital Fastening System:... -
Page 5: Main Power Connection
Main Power Connec- Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to Cable (USA) - Page 6 Lux Output...
-
Page 7: Dmx Profile
DMX Profile Drama Q170 4 Channel Mode DMX Chanel Function Description Value LED Color Red LED intensity 0-255 LED Color Green LED Intensity 0-255 LED Color Blue LED Intensity 0-255 LED Color White LED Intensity 0-255 Drama Q170 7 Channel Mode DMX Chanel Function Description... -
Page 8: Main Control Menu
Main Control The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a control Address of the options and functions. The following will explain each function and its options. - Page 9 White White Dim- This function allows you to dim the white LED . Press Enter use the up/down keys to select desired dimmer settings. Press Enter then ESC to confirm the settings. (255 Steps) Color Fade Color Fade This function allows you to access the pre program fade effect. Press Enter use the up/down keys to select desired fade speed settings.
-
Page 10: Rigging The Fixture
Rigging the fix- Caution! 1. The installations must be carried out by an authorized dealer or trained profes- sional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi- ence including but not limited to calculating working loads, material being used and periodic safety inspections. -
Page 11: Warranty Information
- Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
