  • Page 1: For Windows

    High Performance Document Scanner User Guide User Guide FOR WINDOWS All trademarks are the property of their respective owners and all rights are acknowledged. Images and screenshots used in this User Guide may vary according to the devices used and its operating system. Images and screenshots shown inside are example only.

  • Page 2: Safety And Precautions

    SAFETY AND PRECAUTIONS General Precautions  Never store the unit in hot, or very cold, or humid or dusty places.  For an extended storage period, we recommend storing the unit in a cool and dry place.  If the scanner is left in extreme cold or hot conditions, allow it to adjust to normal room temperatures before use. ...

  • Page 3: Table Of Contents

    CONTENTS SAFETY AND PRECAUTIONS ..............2 Scanning with iDocScan Program ............14 CONTENTS .....................3 Setting Up the Scan Settings ............14 UNPACK ....................4 Scanning a Single-Page Document ..........16 SCANNER PARTS ...................5 Scanning Multi-Page Documents ..........16 SYSTEM REQUIREMENTS ..............6 Overview of the iDocScan Panel ............16 INSTALLATION ..................7 Scanning via TWAIN or WIA interface ..........17 Assembling the Rear Tray ..............7...

  • Page 4: Unpack

    (See p.7) (*) (See p.20) (*) The following are included in the Installation CD:  Scanner Driver (TWAIN and WIA / iDocScan D20 Program/ Hotkey Utility / Calibration Utility) (for Windows)  ABBYY FineReader  ArcSoft Media Impression  Adobe Acrobat Reader...

  • Page 5: Scanner Parts

    Performs Hotkey scanning of the image files. Performs Hotkey scanning of the multi-page PDF D PDF Button files. E PANEL Button Opens the iDocScan D20 program. 5 Flatbed Cover Opens to reveal the Flatbed Glass. 6 Flatbed Glass Holds the single-page document to be scanned.

  • Page 6: System Requirements

    SYSTEM REQUIREMENTS Following minimum system requirements are recommended to obtain the best performance for running your iDocScan scanner.  Computer with Intel Pentium 1.3GHz CPU or higher  SVGA color screen  2GB RAM or greater  USB 2.0 Hi-Speed ...

  • Page 7: Installation

    2. Insert the Rear Tray tabs into the slots on the scanner. The scanner comes with the scanner driver that is packaged with TWAIN / WIA driver, Hotkey Utility and the iDocScan D20 program. You can either scan from any TWAIN-compatible applications by selecting...

  • Page 8: Installing Other Software

    NOTE: If you want to uninstall the scanner driver, be Connecting the Scanner sure to exit the iDocScan D20 hotkey by right-click on 1. Connect one end of supplied Power Adapter to the scanner’s DC IN the icon from the Show Hidden Icons in the taskbar jack, and the other end to a power socket.

  • Page 9: Preparations

    PREPARATIONS Turning On/Off the Scanner Placing Original(s) Power Button Inspecting Original(s) Please inspect your original(s) before scanning to prevent paper jams and protect documents.  Do not use sheets other than those with the specified size, quality, 1. Press the Power Button to turn on the scanner. and weight as the Specification (p.24) to feed in the ADF tray.

  • Page 10: Placing Documents In The Adf

    PREPARATIONS Placing Documents in the ADF 4. Slide either side of the Width Guide to the mark indicating the desired paper size. 1. Fan the stack of the documents to loosen them. 2. Straighten the top edges of the documents on a level of surface. 5.

  • Page 11: Placing Cards In The Adf

    PREPARATIONS Placing Cards in the ADF Placing Document on the Flatbed 1. Place the stack of cards face down with the long side parallel with 1. Lift open the Flatbed Cover. the Width Guides. 2. Place single-page document face down on the Flatbed Glass. 2.

  • Page 12: Scan Operations

     If you cannot find the icon in the taskbar, press Start > All  Choose “Name Card” when scanning business Programs > iDocScan D20 > cards in a batch up to 20 cards. Hotkey Utility to activate it. ...

  • Page 13: Starting Hotkey Scanning

    SCAN OPERATIONS Starting Hotkey Scanning PDF Settings You can perform Hotkey scanning using either the SCAN or PDF Button Check the checkbox to convert document into a text- on the Operation Panel of the scanner, searchable PDF file. Searchable PDF Button Scan Button NOTE: Choose PDF when you need to scan multi-page documents and convert it to a single PDF file.

  • Page 14: Scanning With Idocscan Program

    Scanning with iDocScan Program Properties Description The iDocScan D20 program is specially designed to work with this Choices: “Flatbed”, “ADF (Simplex)”, “ADF (Duplex)”. scanner for easy scanning and other functions.  ADF (Simplex): Choose when scanning multi-page Setting Up the Scan Settings single-sided documents fed in the ADF.
  • Page 15 2GB, otherwise no multi-page TIFF will be created. Control NOTE: Brightness and Contrast does not support the Scan Mode set to “B&W”. For details on functions of the iDocscan D20 program, press the Information tab on the iDocScan D20 main window.

  • Page 16: Scanning A Single-Page Document

    1. Place the original on flatbed.  Refer to the “Placing Original(s)” section for flatbed. The following is a brief overview of the functions of the iDocScan D20 program. For detailed functions of the iDocScan D20 program, press the 2. Press the (Scan) tab to launch the scan setting window.

  • Page 17: Scanning Via Twain Or Wia Interface

    After the preview is complete press the Scan Button. For details on functions of the iDocscan D20 program, press the Information tab on the iDocScan D20 main window. For the ADF (Duplex) and the ADF (Simplex) scanning, press the Scan Button.

  • Page 18: Useful Scanner Features

    By default, the scanner can accept the long paper up to maximum 6. Press the (Exit) button to return to the iDocScan D20 main 635mm in length. The bottom of the scanned image will be cut off if window, and the scanned image(s) will be displayed as thumbnails.

  • Page 19: Maintenance

    MAINTENANCE Cleaning the Scanner Cleaning the Flatbed Glass 1. Use a clean, lint-free cloth sprayed with some mild liquid glass Dust and residues can build up on the Scanner’s rollers and glasses to cleaner. affect image quality. Clean the rollers and glasses periodically to get the best scanning results.

  • Page 20: Calibrating The Scanner

    MAINTENANCE Calibrating the Scanner Replacing the Separation Pad When scanned image’s colors appear not to match the colors of the The Separation Pad in the ADF part is a consumable item. After approx. original, or colors appear in the white areas of the images, calibration 30000 times of scanning, it may become worn.

  • Page 21: Clearing Document Jams In The Adf

    MAINTENANCE 3. Hold the spare Separation Pad and align the springs with the slots Carefully remove the jammed document by pulling evenly with both on the ADF Cover. Press each spring and then push downward until hands to avoid tearing. it locks into place.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Problems Solutions  My computer can’t detect the Check the power supply and cable are connected correctly. scanner or the scanner doesn’t start  Be sure to restart your computer after the scanner driver is installed. scanning.  Check if the power of the scanner is turned on . ...
  • Page 23 TROUBLESHOOTING Problems Solutions  Scanning speed is slow. Adjust the scanner software to reduce the resolution and decrease the file size. Lower quality settings generally results in faster scanning speeds.  The BMP format requires a longer time for scanning than other formats. ...
  • Page 24 TROUBLESHOOTING Problems Solutions  Image saved in the multi-page TIFF Not all applications accept the multi-page TIFF format. Applications that do not support multi-page format cannot be opened by other TIFF format will import and display only the first page of the document. applications.

  • Page 25: Specifications

    SPECIFICATIONS Scanner type Color Duplex ADF (automatic document feeder) and flatbed scanner 20ppm/40ipm (color, 200 dpi, A4, 70 g/m Scan Speed (*) 20ppm/40ipm (gray, 200dpi, A4, 70 g/m 20ppm/40ipm (B&W, 200dpi, A4, 70 g/m Capacity 60 pages at 80 g/m (20 lb), Max thickness: 6 mm (0.24”) Scanning Side Duplex (double sided) and Simplex (single sided)
  • Page 26 SPECIFICATIONS Scan Area Max. 216mm x 300mm (8.5” x 11.8”) Scan Speed (*) approx. 5 sec per page (Color, 300 dpi, A4) Scan Size Auto A4 (W210mm x L297mm / W8.3” x L11.7”) Flatbed A5 (W149mm x L210mm / W5.9” x L8.3”) B5 (W176mm x L250mm / W6.9”xL9.8”) Letter (W216mm x L279mm / W8.5”...
