Mustek S400W User Manual

Wireless scanner for mobile devices and computers
Hide thumbs Also See for S400W:
Table of Contents

Advertisement

Quick Links

Download this manual
Works with
iScan Air
Scanner App
All trademarks are the property of their respective owners and all rights are
acknowledged.
Compatible with iOS, Mac OS X,
Android OS, and Windows 8
Wireless Scanner
Wireless Scanner
For mobile devices, and computers
S400W
Wi-Fi
802.11g/n
Supported
®
POWER
POWER
V1.3

Advertisement

Table of Contents
loading

Related Manuals for Mustek S400W

Summary of Contents for Mustek S400W

  • Page 1 Wireless Scanner Wireless Scanner Works with iScan Air Scanner App For mobile devices, and computers S400W All trademarks are the property of their respective owners and all rights are Wi-Fi ® acknowledged. 802.11g/n Supported POWER POWER Compatible with iOS, Mac OS X, Android OS, and Windows 8 V1.3...

  • Page 2: Safety And Precautions

    Safety and Precautions • Never store the unit in hot, or very cold, or humid or dusty places. • For an extended storage period, we recommend storing the unit in a cool and dry place. • To help keep the scanning area clean, store the unit in a proper case when not in use. •...

  • Page 3: Table Of Contents

    Contents Safety and Precautions ...........2 From Android mobile devices ..........19 Contents ..............3 From Mac computers ............20 Supported Devices ..........4 From Windows 8 devices ............21 Unpack ...............5 Clean Rollers ............22 Scanner Parts ............6 From iPad, iPhone, and iPod touch ........22 Charge the Battery ...........7 From Android mobile devices ..........23 Download and Install iScan Air ......8 From Mac computers ............24...

  • Page 4: Supported Devices

    Supported Devices Wireless Scanner is compatible with following devices: iPad (3rd generation), iPad 2, iPad, iPad mini with iOS 5.0 or later. iPhone 5, iPhone 4S, iPhone 4, iPod touch with iOS 5.0 or later. Android mobile devices (including tablets and smartphones) with OS 4.0 or later. Mac computers with OS X 10.7 or later.

  • Page 5: Unpack

    Unpack Make sure following items are included. POWER POWER Wireless Scanner USB Cable Calibration Card Cleaning Board Cleaning Strip Photo Sleeve User Guide...

  • Page 6: Scanner Parts

    Scanner Parts Wi-Fi LED Indicator Feed Slot Exit Slot Power LED Indicator RESET POWER POWER Reset Pin-hole Paper Guide POWER Button (System Shutdown) Mini USB Port (Charge Only)

  • Page 7: Charge The Battery

    Charge the Battery Wireless Scanner has a built-in rechargeable battery to provide power, make sure it has been fully charged before use. Press POWER button to turn Off the Scanner. The Power LED indicator shall turn off. 2. Connect the USB cable to the Scanner at small end and to a computer ( ) or to USB power adapter (...

  • Page 8: Download And Install Iscan Air

    Download and Install iScan Air Wireless Scanner includes free iScan Air apps to work on iPad, iPhone, iPod touch, Android mobile iScan Air iScan Air devices, Windows 8 devices, and Mac computers. You need to download and install iScan Air from Search ‘iScan Air’...

  • Page 9: From Mac Computers

    Download and Install iScan Air (Continued) From Mac computers Search ‘iScan Air’ in the Mac’s App Store. Open the App Store from your Mac. Type ‘iScan Air’ in the search field. iScan Air iScan Air Select iScan Air and follow on-screen iScan Air instruction to download and install it to Mac.

  • Page 10: From Windows 8 Devices

    Download and Install iScan Air (Continued) From Windows 8 devices Open the Windows Store from your devices.

  • Page 11: Connect Via Wi-Fi Network

    Connect via Wi-Fi Network Wireless Scanner incorporates Wi-Fi capabilities with soft AP (access point) function which enables to share it to multiple devices. Follow below steps to connect Wireless Scanner to your iPad, iPhone, iPod touch, Android mobile devices, Windows 8 devices, and Mac computers via an existing Wi-Fi network in your location.
  • Page 12 Connect via Wi-Fi Network (Continued) Now, Wireless Scanner has been connected to your device successfully and is ready for use. NOTES NOTES • Connection and communication errors may occur during operations due to unexpected factors. If you POWER POWER encounter an error, restart Wireless Scanner and reconnect it via your device again.

  • Page 13: Scan And Save

    Scan and Save NOTES NOTES Ensure Wi-Fi function is enabled on Wireless Scanner and connected to your device prior to use. From iPad, iPhone and iPod touch iScan Air on your device to open it. 2. Place a photo/document facing up, adjust the Paper Guide , slightly push photo/document in until it is gripped by the rollers and pulled into the Feed Slot.

  • Page 14: From Android Mobile Devices

    Scan and Save (Continued) From Android mobile devices iScan Air on your device to open it. 2. Place a photo/document facing up, adjust the Paper Guide , slightly push photo/document in until it is gripped by the rollers and pulled into the Feed Slot.

  • Page 15: From Mac Computers

    Scan and Save (Continued) From Mac computers iScan Air on your device to open it. 2. Place a photo/document facing up, adjust the Paper Guide , slightly push photo/document in until it is gripped by the rollers and pulled into the Feed Slot.

  • Page 16: From Windows 8 Devices

    Scan and Save (Continued) From Windows 8 devices Press on your device to open it. 2. Place a photo/document facing up, adjust the Paper Guide , slightly push photo/document in until it is gripped by the rollers and pulled into the Feed Slot.

  • Page 17: Use The Photo Sleeve

    Use the Photo Sleeve Use the Photo Sleeve when photos are fragile or small to avoid damage or jams, and get the best result. Remove the plastic foil on the Sleeve, place the photo inside of it, insert the tongue into the slot at the open end.

  • Page 18: Calibrate

    Calibrate If dark lines or stripes appeared on the scanned image, please perform the calibration of Wireless Scanner. NOTES NOTES • To get the best scan quality, perform the calibration periodically. • Make sure the Calibration Card is clean and free of dust before use.

  • Page 19: From Android Mobile Devices

    Calibrate (Continued) From Android mobile devices iScan Air app. Tap the (Settings) at the top-right corner of the app to bring up the menu, then select the Calibrate setting. If your Android device has a 'Menu' button press it to bring up the menu.

  • Page 20: From Mac Computers

    Calibrate (Continued) From Mac computers Press iScan Air app. Press the POWER POWER Settings at the top-left corner of the Mac's screen, select the Calibrate setting. Remove the plastic foil on the Calibration Card, insert it in the Feed Slot with the arrow mark facing up and pointing to Wireless Scanner.

  • Page 21: From Windows 8 Devices

    Calibrate (Continued) From Windows 8 devices Press on your device to open it. Press the XXX on the device. Tap XXX at the top-right corner of the app to bring up the menu, and then select the Calibrate setting. Remove the plastic foil on the Calibration Card, insert it in the Feed Slot with the arrow mark facing up and pointing to Wireless Scanner.

  • Page 22: Clean Rollers

    Clean Rollers Dirt and dust can build up inside Wireless Scanner and affect image quality, please clean Wireless Scanner periodically to get the best result. Use the Cleaning Board included with Wireless Scanner to clean rollers. From iPad, iPhone and iPod touch iScan Air app.

  • Page 23: From Android Mobile Devices

    Clean Rollers (Continued) From Android mobile devices iScan Air app. Tap the (Settings) at the top-right corner of the app to bring up the menu, then select the Clean setting. If your Android device has a 'Menu' button press it to bring up the menu.

  • Page 24: From Mac Computers

    Clean Rollers (Continued) From Mac computers Press iScan Air app. Tap the Settings at the top-left corner of the POWER device's screen, select the Clean setting. Hold the Cleaning Board with the sponge stopper strip facing down towards you. Tap the Clean button. * The Cleaning Board will be automatically pulled into Wireless Scanner, wait until the Board is ejected with a 'Cleaning done.' message.

  • Page 25: From Windows 8 Devices

    Clean Rollers (Continued) From Windows 8 devices Press on your device to open it. Press the XXX on the device. Tap XXX at the top-right corner of the app to bring up the menu, and then select the Clean setting. Hold the Cleaning Board with the sponge stopper strip facing down towards you.

  • Page 26: Clean Lens

    Clean Lens Dirt and dust can build up inside Wireless Scanner and affect image quality, please clean Wireless Scanner periodically to get the best result. Please use the Cleaning Strip included with Wireless Scanner to clean the lens. Turn off Wireless Scanner. Hold the Cleaning Strip with the sponge grip handle facing down.

  • Page 27: Helpful Hints

    Helpful Hints Scanner does not turn on. • Check if the POWER button is pressed on. • Check if Wireless Scanner is charged. Scanner cannot connect to a mobile device or computer. • Check if the Wi-Fi signal strength is sufficient. Try moving closer to the Wi-Fi router or base station. •...
  • Page 28 FCC Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 29: Specifications

    Specifications Scanner Type A4 color sheetfed scanner Image Sensor Color CIS (Contact Image Sensor) Light Source LED (R, G, B) Scan Size (Max.) W 216mm x L 356 mm (W 8.5" x L 14") Scan Thickness 0.08mm ~ 0.6mm Scan Resolution 300 dpi Scan Speed 12 seconds per page (A4 color) at 300 dpi...
