Turning the NSO evo2 system on and off

Power
Press the
key/button:
- on the front of the NSO evo2 Processor
- on the front of the monitor (depending on type of monitor and configuration)
- on the OP40 remote controller (accessory)
Home
- on the
page or

How to operate the system

The NSO evo2 multi-function system offers several choices of operation:
Using the touchscreen: Multi-touch gestures for object selection and menu access.
Requires a touchscreen monitor in the system.
Using external controller: Keyboard, Mouse or Trackball connected via the USB port,
or OP40 remote controller connected via the network. For more details, refer to the NSO
evo2 Operator manual and the separate manual for the OP40.

System Controls dialog

Quick access to system settings,
changing between day and night
mode, turning off the NSO evo2
unit, etc.
Activate the dialog by swiping
from the top of the screen or by
Power
pressing a
¼ Note:
The content of the
equipment and active panel.
988-393-002, 1/6
NSO evo2

QuickStart Guide

System Controls
button/key.
System Controls
dialog (turning off only).
dialog depends on connected
EN
